Quick Details
-
color:
-
White
-
Hardness:
-
D95
-
Viscosity:
-
70000cPs@25℃
-
Shelf Life:
-
12 months
-
Specifications:
-
10ML/30ML
-
Product name:
-
UV thermosetting adhesive
-
Application:
-
precision assembly of optoelectronic components
-
Volume shrinkage:
-
1.12%
-
MOQ:
-
30PCS
-
Application material:
-
Plastic, metal, glass
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Aventk
-
Model Number:
-
4034W7
-
color:
-
White
-
Hardness:
-
D95
-
Viscosity:
-
70000cPs@25℃
-
Shelf Life:
-
12 months
-
Specifications:
-
10ML/30ML
-
Product name:
-
UV thermosetting adhesive
-
Application:
-
precision assembly of optoelectronic components
-
Volume shrinkage:
-
1.12%
-
MOQ:
-
30PCS
-
Application material:
-
Plastic, metal, glass
Products Description
|
Brand
|
AVENTK
|
Shelf life
|
12 months
|
|
Place of Origin:
|
Shanghai, China
|
Specifications
|
10ML/30ML
|
|
Product category
|
UV thermosetting adhesive
|
Certification
|
ISO/RoHS/UL
|
|
Chemical types
|
Epoxy resin
|
Application field
|
This glue is a high quality packaging adhesive, mainly used for precision assembly of optoelectronic components, isolators, ROSA,
WDM and other related products |
|
Appearance
|
White liquid
|
Application material
|
Plastic, metal, glass
|
|
Place of Origin
|
Shanghai, China
|
|
Classification
|
UV Adhesives
|
|
Usage
|
precision assembly of optoelectronic components
|
|
Brand Name
|
Aventk
|
|
Model Number
|
4034W7
|
|
Color
|
White
|
|
Viscosity
|
70000cPs@25℃
|
|
Density
|
1.86
|
|
Hardness
|
D95
|
|
Young's modulus
|
9000Mpa
|
|
Bibulous rate
|
0.1%@24H
|
|
Elongation at break
|
N/A
|
|
Tensile strength at break
|
N/A
|
|
Water absorption of boiling water
|
0.4%@2H
|
|
Volume shrinkage
|
1.12%
|
|
Curing band
|
UV curing at 365nm was followed by heating at 110℃
|
AVENTK 4034W7
series UV adhesive -- UV presetting + thermosetting double curing principle, high adhesion, high reliability, waterproof, capricious material, low stress, high TG, high strength, high thixotropic viscosity. This glue can replace EMI-3410-VM.
The glue can be used for the precision assembly of optoelectronic components, the bonding of isolator ROSA, WDM and other materials. It has the characteristics of high viscosity and low thermal expansion coefficient, and is a high-quality packaging adhesive. Better effect with AVENTK UVLED curing system.
Product features:
Uv/high temperature curing
1. Low shrinkage
2. High Tg point
3. Easy to glue
4. Isolate UV light below 400nm
