Quick Details
-
Dimension(L*W*H):
-
570*570*1300 Mm/ Customized
-
Weight (KG):
-
500
-
Product name:
-
Portable Sand Blaster Sandblasting Hoppers Machine
-
Application:
-
Rust Removal, Paint Cleaning
-
Type:
-
Shot Blasting Machine Equipment
-
Blasting Media:
-
Steel Grit
-
Pressure:
-
0.4-8Mpa
-
Volume:
-
0.26-1m3
-
Air Consumption:
-
3m3/min
-
Spraying Gun Diameter:
-
6-12mm
-
After-sales Service Provided:
-
Video technical support
Quick Details
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
YG/ OEM
-
Power:
-
Compressed Air Drive
-
Dimension(L*W*H):
-
570*570*1300 Mm/ Customized
-
Weight (KG):
-
500
-
Product name:
-
Portable Sand Blaster Sandblasting Hoppers Machine
-
Application:
-
Rust Removal, Paint Cleaning
-
Type:
-
Shot Blasting Machine Equipment
-
Blasting Media:
-
Steel Grit
-
Pressure:
-
0.4-8Mpa
-
Volume:
-
0.26-1m3
-
Air Consumption:
-
3m3/min
-
Spraying Gun Diameter:
-
6-12mm
-
After-sales Service Provided:
-
Video technical support
Equipped With Sandblasting Hoppers Water Sand Blasting Machine
Sand blasting machine Technical Parameters:
| Model | YG-600 | YG-700 | YG-800 | YG-1000 |
| Diameter | 600mm | 700mm | 800mm | 1000mm |
| Height | 1150mm | 1250mm | 1700mm | 2000mm |
| Capacity | 0.26m3 | 0.3m3 | 0.6m3 | 1m3 |
| Efficiency | 5-10m²/h | 6-11m²/h | 10-12m²/h | 10-30m²/h |
| Pressure | 0.4-8Mpa | 0.4-8Mpa | 0.4-8Mpa | 0.4-8Mpa |
| Air Consumption | 3m³/min | 3m³/min | 3m³/min | 3m³/min |
Other Model: please contact the salesmanager.
Sand blasting machine Application:
Sandblasting machine widely used in ships, Bridges, mining, machinery, oil pipelines, machine tools, railway, metallurgy, boiler, machinery manufacturing, port construction, water conservancy projects such as surface derusting, smooth surface. It is the most widely used product of abrasive jet, and the sandblasting machine is generally divided into two categories: dry sandblasting machine and liquid sandblasting machine.
Sandblast material: heel-sand huang-san-steel shot steel shot steel grit jade diamond jade
Working principle :
inhaled sandblasting machine is powered by compressed air through the high-speed movement of the air in the gun in the formation of the negative pressure, the abrasive inhalation spray gun and nozzle tube lose sand injection, injection to the processed surface, achieve the desired purpose. In the suction type dry mini sand blasting cabinet, compressed air is both the feed power and the acceleration of jet flow.
Sand blasting machine Features & advantages:
1. Easy operate
2. High efficient
3. H igh precision Sand blasting
4. Can remove the complicated flying side
5. Do not damage the surface
6. L
ess land occupied
Usage scenarios:
Raw material:
