Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LINGZ
-
Model Number:
-
LF35-60
-
Type:
-
Escalators
-
Traveling height:
-
3m--10m
-
Rated Speed:
-
0.5m/s
-
Angle of inclination:
-
35 degree,30 degree
-
Work environment:
-
Indoor and outdoor
-
Step width:
-
1000mm, 800mm, 600mm
-
Cladding:
-
optional
-
Control:
-
VVVF
-
Certificate:
-
ISO9001,ISO14001,OHSAS18001
-
Main Parameter:
-
GB/T705.1-7025.3-2003
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
graphic design, total solution for projects
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LINGZ
-
Model Number:
-
LF35-60
-
Type:
-
Escalators
-
Traveling height:
-
3m--10m
-
Rated Speed:
-
0.5m/s
-
Angle of inclination:
-
35 degree,30 degree
-
Work environment:
-
Indoor and outdoor
-
Step width:
-
1000mm, 800mm, 600mm
-
Cladding:
-
optional
-
Control:
-
VVVF
-
Certificate:
-
ISO9001,ISO14001,OHSAS18001
-
Main Parameter:
-
GB/T705.1-7025.3-2003
1. Escalator Price Specifications
|
Model |
Traveling height (m) |
Inclination angle(°) |
Step width (mm) |
Speed (m/s) |
|
YE35-60 |
4.5 |
35 |
600 |
0.5 |
|
YE35-80 |
4.5 |
35 |
800 |
0.5 |
|
YE35-100 |
4.5 |
35 |
1000 |
0.5 |
|
YE30-60 |
4.5 |
30 |
600 |
0.5 |
|
YE30-80 |
4.5 |
30 |
800 |
0.5 |
|
YE30-100 |
4.5 |
30 |
1000 |
0.5 |
2.The advantageous performances
1.Compact structure
Fish-bellied girder short span of the pedal is mach smaller space,so that the whole structure
more compact,the flexibility to adapt to architectural pattern of the building for customers to
save valuable space.
2.Fine coziness
Advanced control syetems and reducer,high-quality drive chain and precision installasion
process, ensure the products run comfort.
3.Fine safety and reliability
Strict implementation of GB16889-1997<<escalators and moving walkways in the manufacture
and installation of safety norm>>such as modern Chinese and European standards,set all the
necessary safety devices,microcomputer control technology,non-contact control,safe operation
and reliable.
4.Long use life
Use of light weight,high strength metal truss,to ensure product overall rigidity.Automatic
lubrication system,which can guarantee product in time for the parts automatic refueling,
increased product life.
3.Escalator Price Safety Protection
- Hand Strap Inward And Outward Protection
- Comb Foreign Body Safety Protection
- Cascade Drive Chain Loose Fault Protection
- Main Drive Chain Loose Fault Protection
- Host Overheating Protection
- Skirt Safety Protection
- Main Circuit Break Protection
- Prevent Not Operation Reversal Protection
- Over Speed, Speed Limit Protection
- Stair Collapse And Roller Fracture Protection
- Fault Phase Failure Protection
- Emergency Stop Button
- Ground Protection
- Automatic Fault Detection, Display
- Thermal Protection
- Maintenance Socket, Overhaul Box
- Hand Strap Antistatic Wheel
- Stair Anti Static Brush
- Graphical Label Safety Instructions
- Cascade Operation Isolation Plate
- Green Cascade Clearance Lighting (Upper And Lower Ends Level Cascade)
4.Escalator Components:
