- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
HYW-1250-069
-
Type:
-
12 inch short speaker
-
Sensitivity(1w/1m):
-
86dB
-
Frequency Response:
-
37Hz-3kHz
-
Nominal Impedance:
-
4+4 ohm
-
Rated Power:
-
400W
-
Max power:
-
800W
-
Basket material:
-
Die-casting aluminium
-
Magnet material:
-
Ferrite
-
Voice coil diameter:
-
50mm/2 inch
-
Cone material:
-
Carbon
Quick Details
-
Car Fitment:
-
Other
-
RMS Power:
-
400W
-
Frequency Range (Hz):
-
37 - 3000 Hz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM
-
Model Number:
-
HYW-1250-069
-
Type:
-
12 inch short speaker
-
Sensitivity(1w/1m):
-
86dB
-
Frequency Response:
-
37Hz-3kHz
-
Nominal Impedance:
-
4+4 ohm
-
Rated Power:
-
400W
-
Max power:
-
800W
-
Basket material:
-
Die-casting aluminium
-
Magnet material:
-
Ferrite
-
Voice coil diameter:
-
50mm/2 inch
-
Cone material:
-
Carbon
Products Description
|
Specification
|
|
|
||
|
Nominal diameter
|
12
|
mm/inch
|
||
|
Nominal impedance
|
4+4
|
ohm
|
||
|
Min impedance
|
3.6
|
ohm
|
||
|
Frequency response
|
37-3k
|
Hz
|
||
|
Magnet material
|
Ferrite
|
|
||
|
Sensitivity (1w/1m)
|
86
|
dB
|
||
|
RMS power handling
|
400
|
Watts
|
||
|
Continuous power handling
|
800
|
Watts
|
||
|
Voice coil diameter
|
50/2
|
mm/ inch
|
||
|
Winding material
|
Copper
|
|
||
|
Cone material
|
Carbon
|
|
||
|
Surround material
|
Rubber
|
|
||
|
T/S Parameter
|
|
|
||
|
Fs
|
37
|
Hz
|
||
|
Re
|
3.6
|
Ω
|
||
|
Qes
|
0.15
|
|
||
|
Qts
|
0.14
|
|
||
|
Qms
|
3.34
|
|
||
|
Vas
|
7.52
|
L
|
||
|
Cms
|
0.13
|
mm/N
|
||
|
Mms
|
138
|
gr
|
||
|
BL
|
20.3
|
N/A
|
||
|
Mounting information
|
|
|
||
|
Overall diameter
|
315
|
mm/inch
|
||
|
Bolt Circle diameter
|
296
|
mm/inch
|
||
|
Baffle Cutout diameter
|
280
|
mm/inch
|
||
|
Depth
|
107
|
mm/inch
|
||
|
Shipping information
|
|
|
||
|
Net weight
|
4.9
|
KG
|
||
|
Shipping weight
|
5.6
|
KG
|
||
|
Shipping box
|
370x370x150
|
mm
|
||
