Quick Details
-
Brand Name:
-
kellen
-
Voltage:
-
220v
-
Dimension(L*W*H):
-
900*670*1350mm
-
Weight (KG):
-
168
-
Power (kW):
-
0.65
-
Core Components:
-
Other
-
Product name:
-
Circular saw blade grinding machine
-
After-sales Service Provided:
-
Online Support
-
Application:
-
Stainless Steel
-
Name:
-
Surface Grinder
-
Saw blade specification:
-
120-600mm
-
Tooth pitch:
-
3-80mm
-
Wheel speed:
-
2800r/min
-
Grinding wheel size:
-
150*32*10mm
-
Packing size:
-
870*639*1310mm
-
Usage:
-
Grinding Products
Quick Details
-
Wheel Size(mm):
-
150*32*10mm
-
Year:
-
2023
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
kellen
-
Voltage:
-
220v
-
Dimension(L*W*H):
-
900*670*1350mm
-
Weight (KG):
-
168
-
Power (kW):
-
0.65
-
Core Components:
-
Other
-
Product name:
-
Circular saw blade grinding machine
-
After-sales Service Provided:
-
Online Support
-
Application:
-
Stainless Steel
-
Name:
-
Surface Grinder
-
Saw blade specification:
-
120-600mm
-
Tooth pitch:
-
3-80mm
-
Wheel speed:
-
2800r/min
-
Grinding wheel size:
-
150*32*10mm
-
Packing size:
-
870*639*1310mm
-
Usage:
-
Grinding Products
Product Description
Swing water grinding woodworking automatic alloy saw blade grinding machine
In the field of saw blade grinding machine technology, it specifically refers to a new type of electric saw blade grinding machine that can adjust the angle. The saw blade grinding machine uses a combination of a fixed motor and a grinding wheel to grind the saw blade. This structure of the grinding machine achieves efficient operation of mechanical grinding of the saw blade, including a guide rail seat, a grinding wheel working device, a gear working device, and a gear shifting device. The grinding wheel working device includes a transmission motor and a grinding wheel, The transmission motor drives the grinding wheel to rotate, and both the guide rail seat and the gear shifting device are installed on the workbench. The feature is that an adjustment seat is set between the grinding wheel working device and the guide rail seat for vertically adjusting the longitudinal angle of the rotating motor, and an angle adjustment mechanism is set on the adjustment seat that can adjust its horizontal position angle to adjust the angle of the grinding wheel in various directions
Proper operation of equipment
1.Before starting the machine, check whether the voltage and frequency of the motor are consistent with the power supply, and whether the power plug and socket are loose.
2. Pay attention to adjusting the front and rear distance of the push teeth, the left and right distance of the grinding wheel, and the rotation angle of the grinding wheel.
3. Before adjusting, make sure to keep the grinding wheel away from the saw blade and slowly adjust the distance. Do not let the grinding wheel come into contact with the saw blade to avoid collision and damage to the grinding wheel or saw blade.
4. In case of machine malfunction or abnormal sound, the power should be immediately cut off.
5. Do not let the machine run without anyone.
Size Information
|
Model
|
KLQ-67
|
|
Voltage
|
220v/380v
|
|
Power
|
0.65kw
|
|
Saw blade specification
|
120-600mm
|
|
Tooth pitch
|
3-80mm
|
|
Wheel speed
|
2800r/min
|
|
Grinding wheel size
|
150*32*10mm
|
|
Dimension
|
900*670*1350mm
|
|
Packing size
|
870*639*1310mm
|
|
Weight
|
168kg
|
Detailed Images
Applicable to wood processing plants, furniture wood door woodworking machinery aluminum alloy processing plants, all aluminum furniture alloy processing plants, etc
Operation process:
Press the saw blade to be grinded onto the fixed rotating shaft of the saw blade, adjust the gear shifting distance of the gear shifting needle, adjust the grinding angle and feed distance of the grinding wheel, adjust the feed of the grinding wheel after starting up and running, and then automatically finish the grinding of the saw blade.
Real Shot Pictures
Company Introduction
Henan Kellen Machinery Equipment Co., Ltd
Henan Kellen Machinery Equipment Co., Ltd is mainly manufacture the fruit and vegetable juice machine, vegetable dicing machine, ice cube making machine, popcorn machine, dumpling maker machine, strawc rushers, dryer rushers, fresher machine, displayer, flower and display so on. Our machine adopts the latest technology and complied with international quality standard, made of high quality stainless steel with competitive price.Many of our products are exported to America, Australia, France, Netherlands, Ireland and more have got a lot of good feedbacks from clients. "High reputation, Competitive price, Efficient delivery speed and Good after-sell service" is our principal, looking forward to cooperate with more friends from all over the word. If you are of interest of our machine, welcome to contact us any time freely, will try our best to provide you help timely.
Why Choose Us?
Prompt feedback
24hours online, 7 days a week to answer your questions.
Safe payment
We promise payment 100% safe at our account with alibaba trade assurance.
Competitiveness
1) We provide high quality machines at honest price.
2) Practical design and professional advice.
3) Free and correct consultancy for big project or a small scale business.
Easy after-sale service
We have user manual, videos, online/telephone service and reply customers within 24 hours.
Provide free parts damaged or losing during shipment.
Quality guarantee is one year from date of bill of lading.
Upon request, our engineers can go abroad to install commission, and train workers.
