Quick Details
-
Brand Name:
-
Tianshan(TS) filter
-
Material:
-
polypropylene
-
Application:
-
water filter
-
Type:
-
Absolute rating
-
Pore size:
-
0.22um, 0.5um,1um,3um,5um,10um
-
End Cap:
-
222/fin, 222/flat, 226/fin, 226/flat
-
Length:
-
10/20/30 inch
-
Peer:
-
CUNO/3M/pall replacement
-
Samples:
-
Free
-
Diameter:
-
68mm
-
Advantage:
-
Hangzhou factory wholesale
Quick Details
-
Weight (KG):
-
1
-
Core Components:
-
filter
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Tianshan(TS) filter
-
Material:
-
polypropylene
-
Application:
-
water filter
-
Type:
-
Absolute rating
-
Pore size:
-
0.22um, 0.5um,1um,3um,5um,10um
-
End Cap:
-
222/fin, 222/flat, 226/fin, 226/flat
-
Length:
-
10/20/30 inch
-
Peer:
-
CUNO/3M/pall replacement
-
Samples:
-
Free
-
Diameter:
-
68mm
-
Advantage:
-
Hangzhou factory wholesale
PRODUCT CATEGORIES
PARAMETER INFORMATION
|
Absolute rating
|
Imported polypropylene membrane which can provide absolute rating filtration.
|
|
|
Complete Polypropylene structure
|
Made of 100% high quality polypropylene material
|
|
|
Wide chemical compatibility
|
Can be used in the solvent which PH value is from 1 to 13
|
|
|
No media migration into the process fluid
|
All the material have passed the migration test
|
|
|
Effective Filtration Area
|
0.65M2 per 10"
|
|
|
Materials
|
Filter Media: Polypropylene Membrane
|
|
|
|
Support Layers: Polypropylene
|
|
|
|
Inner core: Polypropylene /SUS304
|
|
|
|
Outer Support: Polypropylene Cage
|
|
|
Cartridge Dimensions (Nominal)
|
Outer Diameter: 69mm (2.75")
|
|
|
|
Inner Diameter: 33mm (1.30")
|
|
|
|
Length: 10"- 254mm
|
|
|
|
20"- 508mm
|
|
|
|
30"-762 mm
|
|
|
|
40"- 1016mm * (Length is based on DOE Adapter)
|
|
|
Cartridge Purity
|
Free of surfactants, resins, binders and adhesives
|
|
|
|
Standard: Clean and flushed with Pyrogen-free water
|
|
|
|
Rinse: up to 17-18MΩ.cm with a minimum of throughput
|
|
|
Table 1: Typical water flow rate (10")
|
|
|
|
Typical Applications
|
Pharmaceuticals; APIs; Biologics;Fermentation Broths;Fine Chemicals;Food & Beverages, Wine, Beer, Mineral Water;Semi-Conductor,
LCD Display; Discs |
|
|
Table 2: Liquid Retention Ratings(um) Test
|
|
|
|
Operating Conditions
|
Normal Operating Temperature: Up to 60℃ (140℉)
|
|
|
|
Max.Operating Temperature.: 80℃ (172℉)at△P≤1.0 bar (14psi)
|
|
|
|
Max. Differential Pressure: Normal Flow direction 4.2 bar (60 psi) at 25℃ (77℉);Reverse flow direction 2.1 bar (30psi) at 25℃
(77℉) |
|
|
|
PH Value compatibility: 1-13
|
|
|
Sterilization
|
Steam Sterilization for 30 minutes at 121±2 ℃
|
|
|
|
Cumulative Time:15hours;OR flush with hot water at 82℃(180℉) for 30 minutes at P≤1.0 bar (14psi) -- Recommended.
|
|
|
Materials Safety
|
Meet the current ISO and 2002/72/EC standard
|
|
|
|
Endotoxin: ＜0.25 EU/ml
|
|
|
|
Extractables: 0.03g/ 10"
|
|
|
Table 3: 100% Integrity Test
|
|
|
