Quick Details
-
Tensile Strength:
-
12.5KN
-
11kv shackle insulator:
-
D Iron Insulator, shackle insulator, insulator fitting
-
porcelain insulator:
-
composite insulator
-
electric fence insulator:
-
insulation pin
-
insulator cap:
-
pin inulator
-
electric insulator:
-
glass insulator
-
ceramic insulator:
-
post insulatr
-
porcelain electrical insulator:
-
all types porcelain insulators
-
11kv porcelain insulator:
-
porcelain stay insulator
-
glazed porcelain insulator:
-
33kv porcelain insulator
-
low voltage porcelain insulator:
-
porcelain line post insulator
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
CY, SD
-
Model Number:
-
ED-2B, ED-2C.....
-
Tensile Strength:
-
12.5KN
-
11kv shackle insulator:
-
D Iron Insulator, shackle insulator, insulator fitting
-
porcelain insulator:
-
composite insulator
-
electric fence insulator:
-
insulation pin
-
insulator cap:
-
pin inulator
-
electric insulator:
-
glass insulator
-
ceramic insulator:
-
post insulatr
-
porcelain electrical insulator:
-
all types porcelain insulators
-
11kv porcelain insulator:
-
porcelain stay insulator
-
glazed porcelain insulator:
-
33kv porcelain insulator
-
low voltage porcelain insulator:
-
porcelain line post insulator
D Iron Insulator, shackle insulator, insulator fitting
ED-2B, ED-2C....
|
TYPE |
Fig. No |
Main Dimensions (mm) |
Mechanical Failing load (kN) |
Power frequency Flashover Voltage(kV) |
||||||
|
H |
D |
d |
d1 |
d2 |
R |
Dry |
Wet |
|||
|
ED-2(B) |
2 |
76 |
89 |
83 |
48 |
17.5 |
10 |
13 |
25 |
12 |
|
ED-2(B)1 |
1 |
76 |
92 |
92 |
55 |
18.5 |
9 |
13 |
25 |
12 |
|
ED-2(B)2 |
2 |
76 |
90 |
76 |
50 |
19 |
9.5 |
13 |
25 |
12 |
|
ED-2(B)3 |
2 |
76 |
89 |
76 |
50 |
21 |
9.5 |
13 |
25 |
12 |
|
ED-2(B)4 |
2 |
76 |
89 |
83 |
48 |
21 |
10 |
13 |
25 |
12 |
|
ED-2(C) |
3 |
80 |
80 |
|
50 |
22 |
6 |
13.5 |
25 |
12 |
A. Professional Manufacturer of insulators above twenty years experience
B. Certificates: ANSI, IEC, BS, DIN, XIHARI,AS, SA
C. A wide range of low and high voltage insulators
suspension insulator
spool insulator
shackle insulator
stay insulator
pin insulator
line post insulator
wiring insulator
D. Factory Direct Price
E. Certificate for Insulators
F. We Guarantee best quality which we supplied.
