Quick Details
-
Model Number:
-
EW-2320
-
Certification:
-
CE Certificate
-
Warranty:
-
1 Year
Quick Details
-
Usage:
-
WINDING
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Eastontech
-
Model Number:
-
EW-2320
-
Certification:
-
CE Certificate
-
Warranty:
-
1 Year
1.Step motor driven by constant current power supply high spreading speed precise winding
2. "Start Point" could set by key panel or with teachable function display will show the position of spreading head while setting
3.Small wire diameter products of spreading by nozzletype spreading head
4.Wire passing through ceramic rollers orevent enamel fromnigh temperature.
5.Foot-switch connection for better efficiency.
6. Winding parameters and options can be set independently for each step
7.Memory capacity accommodates 999 steps of parameters with off-power memory retention.
Our Coaxial stripping machine has CE certification
|
Model |
EW- 2320 |
EW- 2320-1 |
|
Number of spools |
1 |
2 |
|
Wire diameter |
0.02-0.8mm |
0.02-0.6mm |
|
Spread pitch |
0-9.999mm |
0-9.999mm |
|
Spread width |
100mm(max.) |
100mm(max.) |
|
Coil diameter |
110mm(max.) |
110mm(max.) |
|
Main motor |
Brushless Motor |
Brushless Motor |
|
Spread motor |
Stepper motor |
S tepper motor |
|
MAX. speed |
6000rpm |
6000rpm |
|
Program Memory |
999 |
999 |
|
Power |
AC220V+10%, 50/60Hz |
AC220V+10%, 50/60Hz |
|
Dimension |
38*48*60cm |
38*48*60cm |
|
Weight |
32kg |
32kg |
