Quick Details
-
Brand Name:
-
WEIER or OEM
-
Product name:
-
304 stainless steel float valve
-
Size:
-
3/4"
-
Material:
-
stainless steel
-
Color:
-
Customized
-
Working Pressure:
-
0.01Mpa-1.0Mpa
-
Connection:
-
Male Thread
-
Certificate:
-
CE
Quick Details
-
Port Size:
-
25mm
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
DS20
-
Brand Name:
-
WEIER or OEM
-
Product name:
-
304 stainless steel float valve
-
Size:
-
3/4"
-
Material:
-
stainless steel
-
Color:
-
Customized
-
Working Pressure:
-
0.01Mpa-1.0Mpa
-
Connection:
-
Male Thread
-
Certificate:
-
CE
Banner
Note:
This product is a liquid level control valve.
Why Choose This
How It Works
Working Principle
When the water level rises up to water limit line which below water level control valve, our valve will stop supplying water at once. When the water level falls down again, our valve will start to supply water automatically.
|
Type
|
Stainless steel Water level control valve
|
|
Customized Support
|
OEM, ODM, OBM
|
|
Brand Name
|
WEIER
|
|
Application
|
General
|
|
Temperature of Media
|
Normal Temperature
|
|
Power
|
Hydraulic
|
|
Media
|
Water
|
|
Certificate
|
CE
|
|
Material
|
Stainless steel
|
|
Work Pressure
|
0.01MPa~1.2MPa
|
|
Life
|
5-10 Years
|
|
Warranty
|
3 Years
|
|
Connection
|
Male Thread
|
|
Water Pressure
|
1.5-174PSI
|
|
Size
|
1/2'', 3/4''
|
【Automatic】
Supply automatically and stop water according to the water level change, saving water, without electricity, long service life.
【Convenient】
Simple installation, convenient maintenance and low failure rate.
【Material】
Made of high quality plastic material that will not rust, long service life, suitable to replace old float valves.
【Application】
Applied to various systems of high water tanks, water towers of the industry and civil construction, etc..
【Service】
Committed to providing high-quality products and the best customer service within 24 hours.
Products Description
After installation, the float must be vertical. If you need to install from the top, you need an elbow to connect the float valve and the inlet line. First, fix the water inlet pipeline on a horizontal surface, and then connect the automatic water level control valve to the water inlet according to the standard. The main water inlet should be aligned with the normal diameter of the control valve. When in use, the shut-off valve should be fully opened. If two valves are installed in the same tank, they should be kept in the same level. Before installation, please clean the impurities in the pipeline to prevent blockage. If the water quality is not good, the valve needs to be properly maintained. If the user finds that the time for adding water becomes longer, he can upload the water inlet and rinse.
