Quick Details
-
Brand Name:
-
VSTARCAM
-
Model Number:
-
CB71
-
Cloud service:
-
Support
-
Product name:
-
Wifi battery camera
-
Resolution:
-
1080P(1920*1080P)
-
Storage:
-
Max 256GB TF/SD Card
-
View angle:
-
145 Degree
-
Battery capacity:
-
1500Mah
-
IR Distance:
-
5-10M Home Camera
-
Certification:
-
ce,FCC,RoHS
Quick Details
-
Function:
-
Wide Angle, Two-way Audio, NIGHT VISION, RESET, Built-in Mic
-
Data Storage Options:
-
Full HD, SD Card, Micro SD card, Cloud, NVR, DVR, NAS, Memory Card
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
VSTARCAM
-
Model Number:
-
CB71
-
Cloud service:
-
Support
-
Product name:
-
Wifi battery camera
-
Resolution:
-
1080P(1920*1080P)
-
Storage:
-
Max 256GB TF/SD Card
-
View angle:
-
145 Degree
-
Battery capacity:
-
1500Mah
-
IR Distance:
-
5-10M Home Camera
-
Certification:
-
ce,FCC,RoHS
Product Description
Product Paramenters
|
Model #
|
|
CB71
|
|
|
|||
|
Operation system
|
|
Embedded Linux OS
|
|
|
|||
|
Online visitor
|
|
Support 4 visitors at the same time
|
|
|
|||
|
Image sensor
|
|
Progressive Scan CMOS
|
|
|
|||
|
Minimum Illumination
|
|
0.3-0.5Lux(color mode), 0 Lux(B&W mode)
|
|
|
|||
|
View Angle
|
|
145˚(Diagonal)
|
|
|
|||
|
Night vision
|
|
Automatic lens sensing switch，6pcs 940nm SMD IR LED, IR irradiation distance:5-10 m
|
|
|
|||
|
Video Encode format
|
|
H.264+/H.264 main profile@level:4.0/Motion-JPEG/JPEG
|
|
|
|||
|
Video Streams
|
|
Main stream:1920*1080@30fps ;Sub stream:640*360@25fps/30fps
|
|
|
|||
|
Video Bit Rate/Max Fps
|
|
128～4096kbps/30pfs
|
|
|
|||
|
Video Image adjustment
|
|
Brightness and contrast can be adjusted
|
|
|
|||
|
Video Encode format
|
|
H.264 main profile/Motion-JPEG/JPEG
|
|
|
|||
|
Audio Input
|
|
Built-in－38±5dB microphone
|
|
|
|||
|
Audio Output
|
|
8Ω0.5W speaker
|
|
|
|||
|
Audio Sampling frequency /Bit width
|
|
8KHz/16bit
|
|
|
|||
|
Audio Compression standard /code rate
|
|
ADPCM/32kbps
|
|
|
|||
|
Network Protocols
|
|
TCP/IP,HTTP,TCP,UDP,DHCP,DNS,NTP,P2P etc
|
|
|
|||
|
Wireless LAN
|
|
IEEE802.11b/g/n, Supports AP mode
|
|
|
|||
|
Wireless LAN Frequency
|
|
2.4~ 2.4835GHz
|
|
|
|||
|
Wireless LAN security
|
|
64/128-bit WEP/WPA-PSK/WPA2-PSK data encryption
|
|
|
|||
|
Memory Socket
|
|
TF Push-push socket,Maximum support 256GB,Cloud storage
|
|
|
|||
|
Alarm Trigger
|
|
Motion detection
|
|
|
|||
|
Rated voltage
|
|
DC5V±5%@Micro USB
|
|
|
|||
|
Power consumption
|
|
Rated power: 2.05W (with infrared lights on) Maximum power: 3.0W(All function on)/Standby power:0.002W
|
|
|
|||
|
Operating condition
|
|
Temperature:-10～50℃,humidity:＜90%
|
|
|
|||
|
Weight
|
|
Net: 60g Gross：210g(Note: in kind prevail)
|
|
|
|||
|
Package size
|
|
133x104x60mm (L×W×H)
|
|
|
|||
|
Warranty
|
|
1 year
|
|
|
|||
|
Ceritifications
|
|
CE,Rohs,FCC
|
|
|
|||
