Quick Details
-
Size:
-
25*17CM, 60CC
-
Product Name:
-
bicycle engine
Quick Details
-
Brand Name:
-
OEM BICYCLE
-
Place of Origin:
-
Zhejiang, China
-
Model Number:
-
OEM-GAS-1
-
Size:
-
25*17CM, 60CC
-
Product Name:
-
bicycle engine
| Specificaton, Performance,and Parameters: | ||||||||||
| 1.Type of petrol engine | 50petal type | 60petaltype | 80petal type | |||||||
| 2.Mode of engine | single cylinder air cooling2:stroke | 60type | 80type | |||||||
| 3.Bore&stroke | 48cm³ | 60cm³ | 80cm³ | |||||||
| 4.Power rotary speed | Rated power | Rated power | Rated power | |||||||
| 1.15kw/5000r/min | 1.5kw/5000r/min | 2.5kw/5000r/min | ||||||||
| (1.6horse power/5000r/min) | (2horse power/5000r/min) | (3horse power/5000r/min) | ||||||||
| Max.Power | Max.Power | Max.Power | ||||||||
| 1.6kw/6000r/min | 2kw/6000r/min | 3.5kw/6000r/min | ||||||||
| (3horse power/6000r/min) | (4-5horse power/6000r/min) | (5-6horse power/6000r/min) | ||||||||
| 5.Ignition Mode | CDI | |||||||||
| 6.Compression ration | 6:01 | |||||||||
| 7.Driving retio | 18:01 | |||||||||
| 8.Fuel | NO.90 | |||||||||
| 9.Lub Oil | oil for 2-stroke petrol enginer(or oil for 10W/40,10W/30) | |||||||||
| 10.Mixing ratio offuel and engine oil | ||||||||||
| 11.Type of sparking plug | Z4C | 14MM | ||||||||
| 12.Valum of oil consumption | 1.5L/100km | 2.0L/100km | 2.5L/100KM | |||||||
| 13.Net weight of main set | 6.5kg | 7.0kg | ||||||||
| 14.Type of clutch | Friction plate | Dry | ||||||||
| 15.Cooling mode | Natural air cooling | |||||||||
| 16.Speed limitation | 30km/hour | 35km/hour | 38km/hour | |||||||
| Mixture of Fuels: | ||||||||||
| This set is of a sort of 2-stroke petral engine,its air drawing with crankcase,it's driving parts of cyliner and crankcase to be lubricated by the fuel system.The fuels of the set adopts the petrol and lub oil.Before filling fuels,mix throughly petrol and lub oil inside a container as per a cortain ratio,then full into the oill tank. | ||||||||||
| You should not allow full into oil tank two kinds of oil respectively, avoid adding pure petrol into the oil tank. | ||||||||||
