Hoops/frames inclued
A. 1 x Shirt Front Round Hoop 9 cm (3.5")
B. 1 x Shirt Front Round Hoop 12 cm (4.7")
C. 1x Shirt Front Round Hoop 15 cm (5.9")
D. 1 x Shirt Front Round Hoop 19 cm (9")
E. 1 x Jacket Back Square Hoop 30 x 30 cm (12" x 12")
F. 1 x Sash Frame 56 x 38 cm (22" x 15")
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
WONYO Embroidery machine
-
Overall Dimensions:
-
1140*1040*1040mm
-
Power:
-
350W
-
Worktable Size:
-
420*550mm
-
Name:
-
Wonyo 2 Head Embroidery Machine
-
Function:
-
Multi Embroidery
-
Application:
-
Cap/t-shirt/Flat/3D/Towel/Leather/Jacket Embroidery
-
Computer:
-
10" Touch Screen Computer
-
Max. speed:
-
1200rpm
-
Needle:
-
9/12/15 Needles
-
Motor:
-
Servo Motor
-
Language Support:
-
16 Languges
-
Memory Size:
-
2.000.000 Stitches
-
Packing:
-
Wooden Case
-
Certification:
-
SGS,CE,ISO
Quick Details
-
Maximum Speed:
-
1000 RPM
-
Operation:
-
Computerized
-
Head Interval:
-
0
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
WONYO Embroidery machine
-
Overall Dimensions:
-
1140*1040*1040mm
-
Power:
-
350W
-
Worktable Size:
-
420*550mm
-
Name:
-
Wonyo 2 Head Embroidery Machine
-
Function:
-
Multi Embroidery
-
Application:
-
Cap/t-shirt/Flat/3D/Towel/Leather/Jacket Embroidery
-
Computer:
-
10" Touch Screen Computer
-
Max. speed:
-
1200rpm
-
Needle:
-
9/12/15 Needles
-
Motor:
-
Servo Motor
-
Language Support:
-
16 Languges
-
Memory Size:
-
2.000.000 Stitches
-
Packing:
-
Wooden Case
-
Certification:
-
SGS,CE,ISO
Product Description
Basic informations
|
Brand
|
WONYO
|
Type
|
embroidery machine
|
|
Model
|
Q401, Q402, Q403
|
Motor
|
servo and stepper
|
|
Operation
|
computerized
|
Warranty
|
2 years
|
|
Head number
|
2
|
Language
|
16
|
|
Needle/Color
|
9/12/15
|
Speed
|
1000RPM
|
|
Certification
|
CE ,SGS
|
Computer
|
10 inch LCD ,touch screen
|
|
Embroidery area
|
400*500cm
|
Worktable size
|
400*500cm
|
|
Overall dimension
|
1425*1030*1040cm
|
Application
|
flat ,cap, garments,logo,3D,leather,etc
|
|
Head interval
|
0
|
Weight
|
470kg
|
|
Package
|
wooden case
|
|
|
Main Features
(1) Suitable for flat embroidery, cap embroidery and finished garments embroidery
(2) Automatic thread trimmer
(3) Maximum speed 1000 RPM
(4) 270 degree Wide cap frame unit
(5) Color LCD display showing real time stitching
(6) USB input port
(7) Automatic color change
(8) Thread break detection
(9) Pre-sew design trace capable
(10) Memory size 20, 000, 000 stitches
(11) Emergency stop
(12) Electricity: 110V/60Hz or 220V/50Hz available
(13) Built-in bobbin winder
14) Keeping current data or work when emergency stop or power off
(15) Mending function. (back and skip stitches under controller)
(16) Switch of Cap/ flat embroidery mode eliminating hitting the frame.
(17) USB port with fast data transmission and good compatibility
(18) Mainboard intergated into control panel protecting from dust or external force.
(19) Lay-out of keys on panel is user-friendly.
(20) Built-in Network
Other Attachment:
1. Table and stander with wheels
2. Extended Table Top
3. Operation Manual
4. Tool Kit
Automatic function :
1.Red laser positioning
2.Automatic motor jump
3.Automatic motor hooking
4. Automatic motor trimming
5.Automatic motor color change
6.Automatic electromagnet deduct thread
Built-in embroidery:
1. Letter embroidery
2. photo embroidery
Opcional devices:
1.sequin embroidery
2.cording embroidery
3.boring embroidery,
4. beads embroidery .
5.taping embroidery
Detailed Images
Packing & Delivery
Certifications
Our Company
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training of machine installation and use
* Engineers available to service machinery overseas.
