SURGEFLO FP-12 12 volt dc motor micro jacking lube oil gear pump

SURGEFLO FP-12 12 volt dc motor micro jacking lube oil gear pump

FOB Reference Price: Get Latest Price

≥1 Sets

US $41

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Standard or Nonstandard:: Standard

Housing Material:: PA66

Volt:: 12V

Flow rate:: 12 L/min Max

Liquid temperature:: 0-60 ℃

Certificate:: Rohs/CE/ISO9001:2000/TUV

Suction:: 1 m

Lift:: 3 m

Quick Details

Pressure:: Low Pressure

Place of Origin:: Fujian, China

Theory:: Rotary Pump

Standard or Nonstandard:: Standard

Housing Material:: PA66

Volt:: 12V

Flow rate:: 12 L/min Max

Liquid temperature:: 0-60 ℃

Certificate:: Rohs/CE/ISO9001:2000/TUV

Suction:: 1 m

Lift:: 3 m

Product Description

SURGEFLO FP-12 12 volt dc motor micro jacking lube oil gear pump

SURGEFLO gear pumps are positive displacement pumps, capable of operation in either direction. They may be used to perform a variety of oil transfer applications (DO NOT USE FOR GASOLINE or other combustible fluids). We use robust motors, stainless steel shafts and rugged metal gears. Our tough design provides performance that you can rely on for years.

Features:

● For use 3.2 GPM(12LPM) open flow output

● Self-priming 3m gear electric pumps suitable for lubricants and viscous liquids

● Rugged bronze body and stainless steel shaft

● pump are built in for intermittent use

● Can be mounted on any position

Application :

Transmission fluid (Diesel; Lubricant; Viscous liquids)
Be able to use for water and machinery fuel(except gasoline)

Industrial use

Pump:

Body Materials	Bronze
Impeller	Bronze
Seal	Lip Type
Port(s)	3/8''Female Thread,1/2''Barbed Fittings Included(12mm) FNPT
Voltage	DC 12V/24V
Amp Draw	Max.10.0(amp)
Fuse Size	15.0(amp)
Motor Type	Permanent Magnet Type Fully Enclosed Stainless Steel Shaft Ball TypeShaft Bearing Reversible Thermally Protected,High Quality Efficient Motor
Self-priming	3.2 feet (1 m) suction lift
Head	9.8 feet (3 m) suction lift
Pressure	Can generate pressures up to 3bar(0.3MPa)
Liquids	Lubricants and visous liquids

Model	Rated voltage (V)	Maximum flow (LPM/GPM )	Gear material	MPa	Rated current(A)	Lift (m)	packing size (mm)	N.W/G.W(KG)
FP-12	12	12.0/3.2	Copper	0.3	8.0	3	190130110	2.52/2.70
FP-24	24	12.0/3.2	Copper	0.3	3.2	3	190130110	2.52/2.70
