Quick Details
-
Voltage:
-
380v/3ph/50hz(or Customized)
-
Dimension(L*W*H):
-
1380*850*1185mm
-
Weight:
-
450KG
-
Product name:
-
electric air compressor for sale
-
Driven method:
-
Driect Driven
-
Cooling method:
-
Air Cooling
-
OEM:
-
Offered/Accepted
-
Noise:
-
Lower Noise
-
Air end:
-
Baosi
-
Motor Power:
-
30kw /40hp
-
Insulation Class:
-
F
-
Application:
-
Industrial Equipment Air Compressor
-
Color:
-
Customized Color
-
Certification:
-
TUV, CE
Quick Details
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
Aivyter
-
Model Number:
-
SGD 30
-
Voltage:
-
380v/3ph/50hz(or Customized)
-
Dimension(L*W*H):
-
1380*850*1185mm
-
Weight:
-
450KG
-
Product name:
-
electric air compressor for sale
-
Driven method:
-
Driect Driven
-
Cooling method:
-
Air Cooling
-
OEM:
-
Offered/Accepted
-
Noise:
-
Lower Noise
-
Air end:
-
Baosi
-
Motor Power:
-
30kw /40hp
-
Insulation Class:
-
F
-
Application:
-
Industrial Equipment Air Compressor
-
Color:
-
Customized Color
-
Certification:
-
TUV, CE
Superior electronic control operating system
By using the intelligent microcomputer control system, the unit with a powerful fault diagnosis and protective function which can work last for 24 hours without watch. If the unit happens to have faults, the system will respond appropriately according to the situations to inform people to replace parts and make the necessary maintenance in time. The operation is very simple, and the unit will change into automatic operation state immediately if people turn on switch.
Economic operation cost
The system uses a 0 ~ 100% displacement of stepless adjustment. The displacement reduces when gas consumption decrease, and the motor current also reduces simultaneously; air compressor runs empty when not using gas, and automatically stops when it runs empty for a long time. When the gas consumption increases, it will recover. It is the best energy saving system.
Good environmental adaptability
Extraordinary cooling system is especially suitable for the high-temperature, high humidity environment in Asia. With the excellent vibration isolation technology and noise reduction measures, the installation of AIVYTER screw air compressors does not need the specialized foundation. You can settle your air compressor only by leaving a minimal ventilation and maintenance space.
Technical Data of Direct Drive Electric Motor Screw Air Compressors
| Model | Motor Power | Working Pressure | Capacity |
Lubricating oil quantity
(L) |
Noise
(dB) |
Dimension(mm) | Net Weight | Air Outlet Pipe Diameter | ||||
| kw/hp | Psi | bar | Cfm | m3/min | L | W | H | KGS | ||||
| SGD08 | 7.5/10 | 102 | 7 | 42.4 | 1.2 | 10 | 66±2 | 900 | 670 | 845 | 220 | 1/2’’ |
| 116 | 8 | 38.8 | 1.1 | |||||||||
| 145 | 10 | 33.5 | 0.95 | |||||||||
| 174 | 12 | 28.3 | 0.8 | |||||||||
| SGD11 | 11/15 | 102 | 7 | 58.3 | 1.65 | 18 | 68±2 | 1000 | 750 | 1015 | 300 | 3/4’’ |
| 116 | 8 | 53 | 1.5 | |||||||||
| 145 | 10 | 45.9 | 1.3 | |||||||||
| 174 | 12 | 38.8 | 1.1 | |||||||||
| SGD15 | 15/20 | 102 | 7 | 88.3 | 2.5 | 18 | 68±2 | 1000 | 750 | 1015 | 300 | 3/4’’ |
| 116 | 8 | 81.2 | 2.3 | |||||||||
| 145 | 10 | 74.2 | 2.1 | |||||||||
| 174 | 12 | 67.1 | 1.9 | |||||||||
| SGD18 | 18.5/25 | 102 | 7 | 113 | 3.2 | 18 | 68±2 | 1130 | 850 | 1175 | 480 | 1’’ |
| 116 | 8 | 105.9 | 3 | |||||||||
| 145 | 10 | 95.3 | 2.7 | |||||||||
| 174 | 12 | 84.7 | 2.4 | |||||||||
| SGD22 | 22/30 | 100 | 7 | 134.2 | 3.8 | 18 | 68±2 | 1130 | 850 | 1175 | 480 | 1’’ |
| 116 | 8 | 127.1 | 3.6 | |||||||||
| 145 | 10 | 113 | 3.2 | |||||||||
| 174 | 12 | 95.3 | 2.7 | |||||||||
| SGD30 | 30/40 | 102 | 7 | 187.1 | 5.3 | 18 | 68±2 | 1130 | 850 | 1175 | 480 | 1’’ |
| 116 | 8 | 176.6 | 5 | |||||||||
| 145 | 10 | 158.9 | 4.5 | |||||||||
| 174 | 12 | 141.2 | 4 | |||||||||
| SGD37 | 37/50 | 102 | 7 | 240.1 | 6.8 | 30 | 68±2 | 1250 | 1000 | 1335 | 500 | 11/2" |
| 116 | 8 | 218.9 | 6.2 | |||||||||
| 145 | 10 | 197.7 | 5.6 | |||||||||
| 174 | 12 | 176.6 | 5 | |||||||||
| SGD45 | 45/60 | 102 | 7 | 261.3 | 7.4 | 30 | 72±2 | 1250 | 1000 | 1335 | 500 | 11/2" |
| 116 | 8 | 247.2 | 7 | |||||||||
| 145 | 10 | 218.9 | 6.2 | |||||||||
| 174 | 12 | 197.7 | 5.6 | |||||||||
|
We emphasize development, and introduce new products into the market every year. Our products sell well
in domestic and international markets, such as Africa and South America, and are favorably appraised by
clients. We pursue the management tenet of "Quality is superior, Service is supreme, Reputation is first",
and will sincerely create and share success with all clients.
|
Q
1
: What is the rotor speed for the air end?
A1:
2980rmp.
Q2: What's your lead
time?
A2: usually, 5-7 days. (OEM orders: 15days)
Q3: Can you offer
water cooled
air compressor
?
A3:
Yes, we can
(normally, air cooled type).
Q
4
: What's
the
payment term?
A
4
: T/T, L/C, Western Union, etc. Also we could accept USD, RMB, and other currency.
Q
5
:
Do
you
accept
customize
d
voltage?
A
5
:
Yes.
380V/
50Hz/
3
ph, 380V
/60H
z/3ph
, 220V/
50Hz/3ph, 220V/60Hz/3ph
, 440V
/
50H
z/3ph, 440V
/60
Hz/3ph
, or as per your requ
ests.
Q
6
: What is your warranty for
air compressor
?
A
6
:
O
ne year
for the whole air compressor(not including the consumption spare parts)
and
technical support
s
can be provided according to your needs.
Q
7
: Can you accept OEM orders?
A
7
: Yes,
OEM orders are
warmly
welcome.
Q
8
: How about your customer service and after-sales service?
A
8
: 24hrs on-line
support,
48hrs problem
so
lv
ed promise.
Q
9
: Do you have s
pa
re parts in stock?
A
9
: Yes
, we do.
Q10:
W
hat
kind of
initial lubrication
oil you used
in air compressor
?
A10: TOTAL
46#
mineral oil.
