Galvanized Clips Razor Wire/Razor Barbed Wire with Clips.
It is a kind of modern security fencing materials with better protection and fencing strength made of hot-dipped galvanized steel
sheets or stainless steel sheets.
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
BW1
-
Name:
-
razor blade wire mesh fence
-
Razor thickness:
-
0.45--0.65mm
-
Wire diameter:
-
1.2mm-2.6m
-
Razor width:
-
15 Mm
-
Razor length:
-
22mm
-
Barb spacing:
-
26 mm
-
Feature:
-
beautiful appearance, economical cost and practicality
-
certification:
-
ISO9001
-
Wire Gauge:
-
BWG12#-BWG15#
-
Coil weight:
-
20-50kg/coil
Quick Details
-
Material:
-
STAINLESS STEEL WIRE
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
BLUEKIN
-
Model Number:
-
BW1
-
Name:
-
razor blade wire mesh fence
-
Razor thickness:
-
0.45--0.65mm
-
Wire diameter:
-
1.2mm-2.6m
-
Razor width:
-
15 Mm
-
Razor length:
-
22mm
-
Barb spacing:
-
26 mm
-
Feature:
-
beautiful appearance, economical cost and practicality
-
certification:
-
ISO9001
-
Wire Gauge:
-
BWG12#-BWG15#
-
Coil weight:
-
20-50kg/coil
Product Description
ROZOR WIRE
Specification
|
Razor Wire Size Specifications
|
|
|
|
|
|
|||||
|
Peference Model
|
Thickness (mm)
|
Wire Diameter (mm)
|
Barb Length
(mm) |
Bard Width
(mm) |
Bard Spacing
(mm) |
|||||
|
BTO-12
|
0.5±0.05
|
2.5±0.1
|
12±1
|
15±1
|
26±1
|
|||||
|
BTO-15
|
0.5±0.05
|
2.5±0.1
|
18±1
|
15±1
|
33±1
|
|||||
|
BTO-22
|
0.5±0.05
|
2.5±0.1
|
02±1
|
15±1
|
34±1
|
|||||
|
BTO-28
|
0.5±0.05
|
2.5±0.1
|
28
|
15
|
45±1
|
|||||
|
CBT-30
|
0.5±0.05
|
2.5±0.1
|
30
|
18
|
45±1
|
|||||
|
CBT-60
|
0.6±0.05
|
2.5±0.1
|
60±2
|
32±1
|
100±1
|
|||||
|
CBT-65
|
0.6±0.05
|
2.5±0.1
|
65±2
|
21±1
|
100±1
|
|||||
|
Outside Diameter
|
No. of Loops
|
Standard Length per Coil
|
Razor Type
|
Notes
|
|
450mm
|
33
|
7M-8M
|
CBT-60, 65
|
Single Coil
|
|
500mm
|
56
|
12M-13M
|
CBT-60, 65
|
Single Coil
|
|
700mm
|
56
|
13M-14M
|
CBT-60, 65
|
Single Coil
|
|
960mm
|
56
|
14M-15M
|
CBT-60, 65
|
Single Coil
|
|
450mm
|
56
|
8M-9M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
500mm
|
56
|
9M-10M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
600mm
|
56
|
10M-11M (3clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
600mm
|
56
|
8M-10M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
700mm
|
56
|
10M-12M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
800mm
|
56
|
11M-13M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
900mm
|
56
|
12M-14M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
960mm
|
56
|
13M-15M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
|
980mm
|
56
|
14M-16M (5clips)
|
BTO-10, 12, 18, 22, 28, 30
|
Cross Type
|
Hot-dipped Galvanized
PVC Painting
Packing & Delivery
Inside waterproof paper ,outside woven bag for razor barbed wire
