Quick Details
-
Brand Name:
-
BOLEO
-
Overall Length(mm):
-
1703/1990/2355
-
Overall Width(mm):
-
767
-
Overall Height(mm):
-
1330
-
Weight(Kg):
-
385/425/455
-
Max.trenching Depth(mm):
-
600/900/1200
-
Fixed Trenching Width(mm):
-
150
-
Hydraulic Flow(L/min):
-
80-110/90-110
-
Max.working Pressure(MPa):
-
21
-
Compatible Carrier:
-
Skid Steer Loader/Loader
-
After-sales Service Provided:
-
Online support
-
After Warranty Service:
-
Video technical support, Spare parts
-
Local Service Location:
-
Canada, United Kingdom, United States, France, Germany, Australia
Quick Details
-
Warranty of core components:
-
14 months
-
Type:
-
Trencher
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
BOLEO
-
Overall Length(mm):
-
1703/1990/2355
-
Overall Width(mm):
-
767
-
Overall Height(mm):
-
1330
-
Weight(Kg):
-
385/425/455
-
Max.trenching Depth(mm):
-
600/900/1200
-
Fixed Trenching Width(mm):
-
150
-
Hydraulic Flow(L/min):
-
80-110/90-110
-
Max.working Pressure(MPa):
-
21
-
Compatible Carrier:
-
Skid Steer Loader/Loader
-
After-sales Service Provided:
-
Online support
-
After Warranty Service:
-
Video technical support, Spare parts
-
Local Service Location:
-
Canada, United Kingdom, United States, France, Germany, Australia
Product Description
FEATURES
●
High Designed to quickly and reliably dig trenches 24, 36, or 48 inches deep
● Tines manufactured from Hardox® steel, service life can be increased by 3 times compared with regular mild steel
●
Trencher chain options cater from soft clean grounds to the hardest of shale, Earth Teeth trench in soft earth, Combination Teeth Trench in all ground conditions includes mixed rocky grounds
● 6”, 8” and 10” chain widths available
●
Available in a number of different tooth configurations for trenching in soft ground, mixed grounds and even permafrost so you can get the job done no matter what environment you are in
● USA made Eaton® direct drive motor ensures optimum performance and longevity and allows forward and reverse operation
●
Adjustable auger can clears loose soil from the trenching area, it can also be removed if not needed
● Universal Mounting Quick Attach, included to suit your machine
●
Heavy frame construction stands up to everyday rugged use
● Machined and enclosed front bearings are protected against dirt and offer extended life
|
SPECIFICATIONS
|
|
|
|
|||
|
Model
|
BTR24
|
BTR36
|
BTR48
|
|||
|
Overall Length(mm)
|
1703
|
1990
|
2355
|
|||
|
Overall Width(mm)
|
767
|
767
|
767
|
|||
|
Overall Height(mm)
|
1330
|
1330
|
1330
|
|||
|
Weight(Kg)
|
385
|
425
|
455
|
|||
|
Max.trenching Depth(mm)
|
600
|
900
|
1200
|
|||
|
Fixed Trenching Width(mm)
|
150
|
150
|
150
|
|||
|
Hydraulic Flow(L/min)
|
80-110
|
90-110
|
90-110
|
|||
|
Max.working Pressure(MPa)
|
21
|
21
|
21
|
|||
