Automatic 20 liter jerry can 8 heads thick peanut vegetable plant olive cooking edible oil bottle filling machine

Automatic 20 liter jerry can 8 heads thick peanut vegetable plant olive cooking edible oil bottle filling machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $12000

≥5 Sets

US $3000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Filling Accuracy:: ±2mm

Voltage:: 380V/220V

Place of Origin:: Jiangsu, China

Brand Name:: PAIMA

Dimension(L*W*H):: 2400*1300*2200mm

Weight:: 800-1200KG

Name:: oil filling machine

Bottle type:: PET Plastic Bottle

Capacity:: 1000-5000bph

Material:: Stainless Steel 304/316

Filling Accuracy::: ±3g

Filling range:: 100-5000ml

Control system:: PLC+ Touch Screen

Filling heads:: 4 - 24 Heads

Cap Type:: Screw cap / Pressing Cap

Certification:: CE ISO

Marketing Type:: New Product 2021

Quick Details

Machinery Capacity:: 4000BPH, 2000BPH, 1000BPH

Packaging Material:: Plastic, Metal, Glass

Filling Material:: Beer, Milk, Water, Oil, Juice

Filling Accuracy:: ±2mm

Voltage:: 380V/220V

Place of Origin:: Jiangsu, China

Brand Name:: PAIMA

Dimension(L*W*H):: 2400*1300*2200mm

Weight:: 800-1200KG

Name:: oil filling machine

Bottle type:: PET Plastic Bottle

Capacity:: 1000-5000bph

Material:: Stainless Steel 304/316

Filling Accuracy::: ±3g

Filling range:: 100-5000ml

Control system:: PLC+ Touch Screen

Filling heads:: 4 - 24 Heads

Cap Type:: Screw cap / Pressing Cap

Certification:: CE ISO

Marketing Type:: New Product 2021

Product Overview

Full automatic Oil filling machine

This machine is a new generation of packaging equipment that is arbitrarily adjustable from 1 liter to 5 liters designed for the packaging of lubricating oil, edible oil and other oil products. Use microcomputer PLC automatic control. Man-machine interface, fully enclosed, submerged filling. It has high measurement accuracy, large filling range, compact structure and stable operation. Suitable for filling various regular-shaped containers. The liquid cylinder and its pipes can be disassembled and cleaned conveniently and quickly. All parts in contact with the material and liquid are made of SUS304/316 stainless steel, the whole machine is beautiful and generous. Conforms to GMP standards. It adopts servo control and piston filling form. PLC and man-machine control interface. With four groups of dose adjustment memory data, it is more convenient to change the dose. It is equipped with online weighing feedback system combined with PLC system to automatically adjust the influence of oil volume and temperature on filling accuracy in real time.

PRODUCT SPECIFICATIONS

Cooking oil , vegetable oil / olive oil / engine oil filling machine

Bottle Material: PET Bottle

Cap: Screw cap, threaded aluminum cap Rolled aluminum cap etc

Bottle Volume: 1L-5L

Production Speed: 960-2880bph

Suitable Bottle:

Height 170-320mm

Diameter 20-110mm

Oil bottle filling machine
Model	PM-GF-4H	PM-GF-6H	PM-GF-8H	PM-GF-10H	PM-GF-12H
Dimnesion (mm)	2000 x1000x2400	2000 x1000x2400	2280 x1000x2400	2400 x1000x2400	2400 x1000x2400
Filling Heads	4	6	8	10	12
Bottle volume (5L, bph)	1L-5L					1200	1460	1800	2880
Capacity	960	1200	1460	1800	2880
Filling accuarcy	±3g	±3g	±3g	±3g	±3g
Power	220V / 380V 50 / 60HZ
Voltage (KW)	1.1	1.5	2.2	3.0	4.0
Air pressure	0.55MPa~0.65MPa

Devices	Brand	Origins
PLC	SIEMENS	Germany
Inverter
Touch Screen
Switch
Contactor
Relayer
Solenoid Valve	AIRTAC	Taiwan, China
Drive motor	FEITUO	Swiss
Reducer	CNP	China
Water Pump	SKF	China
Main Bearing	AUTONICS	Sweden
Sensor	AIRTAC	Korea
Air component	ABB	Taiwan, China

FEATURES AT A GLANCE

Features of automatic oil filling machine

1. The weighing instrument is a dedicated controller for quantitative packaging scales, with fast response, high precision and complete functions.

2. The load cell is a Toledo intrinsically safe sensor, which is sealed with multi-layer media and has strong anti-eccentric load capability. It has the characteristics of dustproof, waterproof, explosion-proof, button resistance and corrosion resistance, and meets the IP67 sealing standard.

3. The flow of materials is controlled by the double-speed ball valve and the bottom valve of the spray gun, which is accurate and reliable. The user can adjust the filling speed through the instrument keyboard.

4. This machine adopts programmable controller (PLC), touch screen operation control, easy to use and adjust.

5. Adopting unique software and hardware design, which can effectively prevent material from dripping and leakage, and ensure the cleanliness of filling equipment and packaging containers.

6. Each filling head has a weighing and feedback system, which can set and micro-adjust the filling volume of each head.

7. The filling method is submersible, which can effectively reduce the generation of foam and meet the filling of materials with different characteristics.

8. Adopting advanced sensing elements to achieve no barrels and no filling. When the barrels are blocked, the host will automatically stop and give an alarm.

PRODUCT CONFIGURATION

Filling Pipes:

According to the customer's different choice, can be equipped with different materials of pipe, to meet the customer variety of different liquid safe filling.

1. Teflon corrugated pipes

This pipe is suitable for edible oil,lube oil,liquid detergent,liquid soap,hand sanitizer,etc.it is suitable for various viscosity and non- viscosity liquid.

2. Food-grade silicone hoses

This pipe is suitable for Mustard sauce, mayonnaise, chili sauce, ketchup and other sauce materials,etc. Filling with non- residue.

3. Food grade rubber hoses

This pipe is suitable for edible oil, Ketchup, hot sauce,etc. it will strength enough and will not pollute the food material.

Piston Rings:

1.According to different filling materials, we will use different quality of piston rings.

2.White is usually used in filling edible oil products,the black one usually used in industry oil.

3.Both these two kind of piston rings are made of Teflon material，inside the rings is a spring，it has the function of automatic adjust the gap caused by friction.So that the piston rings have a long-service time.

Pressure Capping Machine

This machine applies and torques caps into containers . It's suitable for various material and figure containers . Such as plastic bottles , glass bottle , and metal bottle . If we want to change different material or figure bottles and caps for tightening , we do not need change any components . We just adjust the position of several components . No bottle no cap falling .Cap unscrambler machine , conveyor ,cap screw parts, bottle clamping strap can be conversion adjusted to meet the tightening requirements for various bottles and caps . The machine is made of good type stainless steel , also applied to GMP standard requirement . (custom-tailoring diversified for special specification )

1. There is no need to replace the parts when changing the bottle shape, just adjust the position of some parts. The machine is simple in structure and easy to adjust.

2. When use pressure capping type,this machine can be changed into pressure capping type machine.

Screw capping machine

The machine adopts linear bottle feeding, PLC program control, double cylinder bottle positioning, can clear up and drop the cap automatically. Single-head machine in the double action lifting cylinder to grasp the cover firstly, then screw cap. The screw cap adopts the air expansion type catch cap, and is equipped with torque control, the screw cap will not damage the bottle cap, the machine is suitable for the screw cap of the barrel with large diameter.

1. Servo Mortor Capping

Servo motor is used to control the torque of the rotary capping head,It won't damage the bottle and the caps. The action of grasping the cap is completed by the air cylinder.

2. Easy Adjustment The capping head can be disassemble independent,when change the cap size,you can change the capping head to fix new productions

3.Linear Cap Unscrambler

Linear cap unscrambler machine for cap sorting, Belt type conveyor for the caps,the speed and stability of cap conveyor are increased, and won't occurs caps missing.

Automatic sticker labeling machine

Automatic double-side labeling machine for square bottles or flat shape of things off the side of the bottle labels ,which can be applied in many industries for automatic labeling and other irregular shape of the bottles.

Easy operation
Adopt mature PLC control technology, make the machine stable and high-speed.Can be suitable or square flat bottles at the same time.Adopt touch screen control system, simple,practical and efficient operation

Easy Adjustment
Adopt high quality sponge wheel to leave some space between the bottles, so as to ensure that the labels will not be missed. The rotary speed of the sponge wheel can be adjusted to adjust space between the two bottles.

Widely Use The parts of the machine that store labels and collect label paper are designed to be adjustable to accommodate a wide variety of labels. Special Customization

we can making the labeling machine can suitable for square bottle,flat bottle and round bottles at the same time. When change the bottle from square or flat to the round bottles,it is only need a simply adjust on this machine.

High Accuracy

Adopt photoelectric equipment imported from Germany, and high quality servo motor, the labeling accuracy is greatly improved.

Full line of products

Complete oil bottle filling line

1. Bottle making system

pet preform→Autoloader→reheater →molding→ bottles

2. Bottle filling system

Full automatic oil Filling machine→Capping machines

3. Packing system

Full-automatic labeling machine →Inkjet machine →Full automatic PE film packing machine / Carton packing machine→ warehouse
