Quick Details
-
Fuel:
-
Gasoline
-
Place of Origin:
-
Shandong, China
-
Displacement:
-
400cc, 400cc
-
Horse Power:
-
18kw(6500r/min) 25HP
-
Top speed:
-
75km/h
-
Transmission:
-
CVT
-
Brake:
-
4 wheel-hydraulic disc brake
-
Color:
-
green,red,blue,orange
-
Final Drive:
-
shaft-drive
-
Drive Line Type:
-
4x2
-
Ignition System:
-
D.C.D.I
-
Suspension:
-
Front: double A-Arm, Rear: FANG POWER 4 Link Bar rear suspension
Quick Details
-
Brand Name:
-
FANGPOWER
-
Tire Size:
-
25x8-12 / 25x10-12
-
Dimension:
-
2700x1450x1750mm
-
Fuel:
-
Gasoline
-
Place of Origin:
-
Shandong, China
-
Displacement:
-
400cc, 400cc
-
Horse Power:
-
18kw(6500r/min) 25HP
-
Top speed:
-
75km/h
-
Transmission:
-
CVT
-
Brake:
-
4 wheel-hydraulic disc brake
-
Color:
-
green,red,blue,orange
-
Final Drive:
-
shaft-drive
-
Drive Line Type:
-
4x2
-
Ignition System:
-
D.C.D.I
-
Suspension:
-
Front: double A-Arm, Rear: FANG POWER 4 Link Bar rear suspension
Product Description
Product specification
|
ENGINE
|
|
SUSPENSION / BRAKES
|
|
|
Final Drive
|
Shaft-drive
|
Suspension Front
|
Double A-arm Suspension
|
|
Engine type
|
4-stroke,Single-Cylinder, Water-cooled
|
Suspension Rear
|
Fang power 4-Link® bar Rear Suspension
|
|
Horse Power
|
18KW ( 6500rpm) 25HP
|
Brakes Front
|
220MM Front Dual Hydraulic Disk
|
|
Valve Configuration
|
SOHC
|
Brakes Rear
|
220MM Rear Dual Hydraulic Disk
|
|
Compression ratio
|
10.0:1
|
TIRES
|
|
|
FUEL SYSTEM
|
|
Front Tread
|
1250mm ( 49.2 in)
|
|
Fuel Delivery System
|
Fuel Pump Carburetor
|
Rear Tread
|
1150mm ( 45.2in)
|
|
Choke System
|
Automatic
|
Front & Rear tire size
|
25x8-12 / 25x10-12
|
|
Fuel capacity
|
9.5L (2.1 Gallon)
|
MISC
|
|
|
DRIVETRAIN
|
|
Loading information
|
2units/20″;;8units/40HQ
|
|
Driveline Type
|
4X2
|
Manufacturers Warranty
|
6 Months
|
|
Transmission
|
Constantly Variable Transmission
|
Top speed
|
75km/h
|
|
Gear Selection
|
Forward & Reverse Single Speed
|
Dry weight
|
500KGS
|
|
ELECTRICAL SYSTEM
|
|
Gross weight
|
560kgs
|
|
Forward Lights
|
Headlights-High & Low Beam
|
Wheelbase
|
1980mm (78in)
|
|
Rear Lights
|
Brake Lights & Left/Right Signal lights
|
Vehicle dimension(L×W×H)
|
2700x1450x1750mm
|
|
Starting system
|
Electric start
|
Packing size
|
2700x1400x815mm
|
|
Ignition system
|
D.C.D.I
|
Ground clearance
|
300mm(11.8in)
|
|
Cargo box
|
Cargo box: 700*1100mm
|
Safety
|
Driver & Passenger Seat belts/ Driver and Passenger safety net restraints.
|
