Quick Details
-
Color:
-
.
-
Panel Size:
-
., .
-
Supplier Type:
-
other
-
Place of Origin:
-
Taiwan, China
-
Model Number:
-
AC20VI-RGCA
-
use:
-
other
-
Pixel Pitch:
-
., ., .
-
Specification:
-
other
-
Dominant Wavelength:
-
625nm
-
Forward Voltage:
-
1.9-2.4v
Quick Details
-
Application:
-
Indoor, Outdoor
-
Type:
-
LED
-
Brand Name:
-
Super Brite/ All Brite
-
Color:
-
.
-
Panel Size:
-
., .
-
Supplier Type:
-
other
-
Place of Origin:
-
Taiwan, China
-
Model Number:
-
AC20VI-RGCA
-
use:
-
other
-
Pixel Pitch:
-
., ., .
-
Specification:
-
other
-
Dominant Wavelength:
-
625nm
-
Forward Voltage:
-
1.9-2.4v
Specification
0.2 inch 6 Digit SMD 7 Segment LED Display
AC20VI-RGCA
Product Description
Mechanical Dimensions
Features
•
0.20 inch (5.08mm) digit height
•
Qualified according to JEDEC moisture sensitivity Level 2a.
• RoHS compliant.
• Low power consumption.
• Black face, white segment
•
Easy mounting on P.C. board
Absolute Maximum Rating
|
Parameter
|
Symbol
|
Rating
|
Unit
|
|
Power Dissipation Per Dice
|
PAD
|
70
|
mW
|
|
Derating Linear from 25℃ per Dice
|
-
|
0.33
|
mA/℃
|
|
Continuous Forward Current Per Dice
|
IAF
|
25
|
mA
|
|
Peak Current Per Dice (duty cycle 1/10,1KHz)
|
IPF
|
90
|
mA
|
|
Reverse Voltage Per Dice
|
VR
|
5
|
V
|
|
Operating Temp.
|
Topr
|
-40 ~ +105
|
℃
|
|
Storage Temp.
|
Tstg
|
-40 ~ +105
|
℃
|
Electro-optical Characteristics
Reel Dimension (Unit: mm )
