Quick Details
-
Brand Name:
-
Non-brand
-
Model Number:
-
AC027
-
Product Name:
-
RF Transceiver
-
Plug Type:
-
No plug
-
Support APP:
-
rf433mhz
-
Color:
-
As picture
Quick Details
-
Max. Current:
-
10A
-
Network:
-
RF
-
Place of Origin:
-
China
-
Brand Name:
-
Non-brand
-
Model Number:
-
AC027
-
Product Name:
-
RF Transceiver
-
Plug Type:
-
No plug
-
Support APP:
-
rf433mhz
-
Color:
-
As picture
We have two version : 433mhz And 315Mhz, you confirm what version you need before order.
And the remote controller key not including, if you need we will confirm the key price extrally.
Input Voltage: 12 V
• Receiver sensitivity: > 97 dbm
• Transmitting distance:> 100 m ( open space)
• Decoding mode: MCU software decoding
• Remote storage: 20
• Support remote type : Learning code (1527/2240 chip) fixed code
• Working mode: Momentary, toggle, latching time delay (5s ,10s ,15s )
• Output terminal: NO , NC , COM
Note: Maximum input power is 12 V
Working mode:
1. Inching mode: press the remote control the relay will connect , and then release the remote controlto disconnect the relay;
2. Self-locking mode: press the remote control the relay will connect , and then press the remote control again to disconnect the relay;
3. Interlock mode: press the remote control key A to connect the relay, and press the remote control key B to disconnect relay .
4. Delay mode: press the remote control the relay will connect , release the remote control and start timing. After 5 S , 10 S and 15 S (3 gear s ), the relay will be automatically closed.
Learning Methods:
1. Inching learning method:
Press the code pairing button on the control panel once, and the LED indicator will flash once. After the LED indicatorlit, press the button you need to pairing on the remote control , the LED indicator on the control panel will flash for 3 times which means the pairing succeed .
2. Self-locking learning method:
Press the code pairing button on the control panel twice , and the LED indicator will flash twice . After the LED indicatorlit, press the button you need to pairing on the remote control , the LED indicator on the control panel will flash for 3 times which means the pairing succeed .
3. Mutual lock learning method:
Press the code pairing button on the control panel three times , and the LED indicator will flash three times . After the LED indicatorlit, press the button you need to pairing on the remote control , the LED indicator on the control panel will flash for 3 times which means the pairing succeed .
4. 5S delay learning method:
Press the code pairing button on the control panel four times , and the LED indicator will flash four times . After the LED indicatorlit, press the button you need to pairing on the remote control , the LED indicator on the control panel will flash for 3 times which means the pairing succeed .
5. 10 S delay learning method:
Press the code pairing button on the control panel f ive times , and the LED indicator will flash five times . After the LED indicatorlit, press the button you need to pairing on the remote control , the LED indicator on the control panel will flash for 3 times which means the pairing succeed .
6. 15 S delay learning method:
Press the code pairing button on the control panel six times , and the LED indicator will flash six times . After the LED indicatorlit, press the button you need to pairing on the remote control , the LED indicator on the control panel will flash for 3 times which means the pairing succeed .
Clear ing method :
Press the code pairing button on the control panel eight times , then it will automatically clear all the learned remote controls.After clearing, the remote control previously learned can no longer be used .
