Quick Details
-
Brand Name:
-
RAYMATES
-
Model Number:
-
RM-COBW420-12A110/220
-
CRI (Ra>):
-
90
-
Lamp Luminous Efficiency(lm/w):
-
60-90
-
Lamp Luminous Flux(lm):
-
1000LM/M
-
Working Lifetime(Hour):
-
50000
-
Working Temperature(℃):
-
-20 - 60
-
Product Weight（kg）:
-
0.1
-
Product Name:
-
High Voltage COB Strip Light
-
Emitting Color:
-
2700K-6500K
-
LED Quantity:
-
420 LEDs/m
-
Package:
-
10m/roll 20m/roll 50m/roll
-
PCB Width:
-
12mm
-
PCB thickness:
-
2 Ounce Copper
-
Beam Angle:
-
180 Degree
-
Switch Mode:
-
Remote Control
Quick Details
-
Color Temperature(CCT):
-
2700K-6500K
-
Control Mode:
-
Touch Control, APP Control, Remote Control, Switch Control, Voice control, Sensor control, Other
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
RAYMATES
-
Model Number:
-
RM-COBW420-12A110/220
-
CRI (Ra>):
-
90
-
Lamp Luminous Efficiency(lm/w):
-
60-90
-
Lamp Luminous Flux(lm):
-
1000LM/M
-
Working Lifetime(Hour):
-
50000
-
Working Temperature(℃):
-
-20 - 60
-
Product Weight（kg）:
-
0.1
-
Product Name:
-
High Voltage COB Strip Light
-
Emitting Color:
-
2700K-6500K
-
LED Quantity:
-
420 LEDs/m
-
Package:
-
10m/roll 20m/roll 50m/roll
-
PCB Width:
-
12mm
-
PCB thickness:
-
2 Ounce Copper
-
Beam Angle:
-
180 Degree
-
Switch Mode:
-
Remote Control
Product parameters
|
Model No.
|
RM-COBW420-12A110/220
|
|
LED Type:
|
COB
|
|
Volateg:
|
110Vac/220Vac
|
|
LED QTY:
|
420LEDs/m
|
|
Color:
|
2700K,3000K,4000K,6000K
|
|
Power:
|
14W/m
|
|
Lumens:
|
800-1000lm/m
|
|
PCB Width:
|
10mm
|
|
Waterproof Grade:
|
IP67
|
|
Beam Angle:
|
180°
|
|
PCB Thickness:
|
3 Ounces
|
|
Standard Length:
|
10M/roll 20M/roll 50m/roll
|
|
Dimension:
|
W12*L50,000mm
|
|
Warranty:
|
3 Years
|
COB light strip definition
The LED COB Strip's full name: Chip-On-Board, which is a production technology the low-power chips are directly encapsulated on the PCB board. Fastest heat dissipation.
The Traditional SMD LED Strip is made of chips on the frame and made into SMD. Then put the LEDs on the PCB board. COB tape light saves lots of costs and space on the PCB. For example, SMD 2110 strip light can hold a maximum of 700 LEDs per meter. However, the COB led strip can hold 1056 chips or more. And because the cost of mounting the Chip on the frame is saved, the price of the COB LED strip is much Cheaper than the same number of led strips.
The Traditional SMD LED Strip is made of chips on the frame and made into SMD. Then put the LEDs on the PCB board. COB tape light saves lots of costs and space on the PCB. For example, SMD 2110 strip light can hold a maximum of 700 LEDs per meter. However, the COB led strip can hold 1056 chips or more. And because the cost of mounting the Chip on the frame is saved, the price of the COB LED strip is much Cheaper than the same number of led strips.
Advantages
1, Flip-chip, new technology against traditional strip.
2, High density LEDs, no darkness.
3, Beam angle 180°, homogeneous illumination.
4, Extremely flexible, bending diameter >10mm.
5, Excellent heat dissipation.
2, High density LEDs, no darkness.
3, Beam angle 180°, homogeneous illumination.
4, Extremely flexible, bending diameter >10mm.
5, Excellent heat dissipation.
