Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Jialong Baofeng
-
Dimension(L*W*H):
-
500*430*475 mm
-
Weight:
-
29
-
Rated power/speed:
-
15hp/3600rpm
-
Marketing Type:
-
New Product 2023
-
Engine Model:
-
190 F
-
Rated Power:
-
15 hp
-
Color:
-
Red
-
Cooling System:
-
Forced Air-cooled
-
Packing:
-
Carton
-
Fuel Tank Capacity:
-
6.5 L
-
After Warranty Service:
-
Video technical support
-
Oil Capacity:
-
1.1 L
-
Bore*Stroke:
-
90*66 mm
Quick Details
-
Displacement:
-
420 cc, 420 cc
-
Emission Standard:
-
Other
-
Power:
-
15HP
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Jialong Baofeng
-
Dimension(L*W*H):
-
500*430*475 mm
-
Weight:
-
29
-
Rated power/speed:
-
15hp/3600rpm
-
Marketing Type:
-
New Product 2023
-
Engine Model:
-
190 F
-
Rated Power:
-
15 hp
-
Color:
-
Red
-
Cooling System:
-
Forced Air-cooled
-
Packing:
-
Carton
-
Fuel Tank Capacity:
-
6.5 L
-
After Warranty Service:
-
Video technical support
-
Oil Capacity:
-
1.1 L
-
Bore*Stroke:
-
90*66 mm
Product Paramenters
Model
|
JL-168FEG
|
JL-170FEG
|
JL-177FEG
|
JL-188FEG
|
JL-190FEG
|
JL-192FEG
|
|||||
Engine Type
|
OHV, Single Cylinder, Air-cooled, 4 Stroke
|
OHV, Single Cylinder, Air-cooled, 4 Stroke
|
OHV, Single Cylinder, Air-cooled, 4 Stroke
|
OHV, Single Cylinder, Air-cooled, 4 Stroke
|
OHV, Single Cylinder, Air-cooled, 4 Stroke
|
OHV, Single Cylinder, Air-cooled, 4 Stroke
|
|||||
Fuel
|
Gasoline
|
Gasoline
|
Gasoline
|
Gasoline
|
Gasoline
|
Gasoline
|
|||||
Starting System
|
Electric
|
Electric
|
Electric
|
Electric
|
Electric
|
Electric
|
|||||
Battery
|
12V7A
|
12V7A
|
12V17A
|
12V17A
|
12V17A
|
12V17A
|
|||||
Compression Ratio
|
8.5:1
|
8.5:1
|
8.2:1
|
8.0:1
|
8.0:1
|
8.3:1
|
|||||
Bore*Stroke
|
68*54mm
|
70*55mm
|
77*58mm
|
88*64mm
|
90*66mm
|
92*66mm
|
|||||
Displacement
|
196cc
|
212cc
|
270cc
|
389cc
|
420cc
|
439cc
|
|||||
Horsepower
|
6.5hp
|
7.0hp
|
9hp
|
13hp
|
15hp
|
17hp
|
|||||
Fuel Tank Capacity
|
3.6L
|
3.6L
|
6L
|
6.5L
|
6.5L
|
6.5L
|
|||||
Oil Capacity
|
0.6L
|
0.6L
|
1.1L
|
1.1L
|
1.1L
|
1.1L
|
