Quick Details
-
Model Number:
-
YK
-
Max. Current:
-
3A-6A
-
Max. Working Pressure:
-
4.6Mpa
-
Setting range of pressure:
-
3-667PSI/0.02-4.6mpa
-
Tolerance range of pressure switch:
-
1.45-14.5PSI/0.01-0.1mpa
-
Contact capacity:
-
AC240V,3A, AC120V,6A
-
Maximum burst pressure:
-
No breakdown and flashing in 1min at AC 1500V
-
Life cycle:
-
100000times
-
Application:
-
Protect and control high and low pressure
-
Types:
-
Thread,plug,capillary,copper pipe,wire
-
Sensor:
-
sealed stainless steel sensor
-
contact structure:
-
SPST or SPDT
-
Certification:
-
CE,UL
Quick Details
-
Max. Voltage:
-
220-240v
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
DULING
-
Model Number:
-
YK
-
Max. Current:
-
3A-6A
-
Max. Working Pressure:
-
4.6Mpa
-
Setting range of pressure:
-
3-667PSI/0.02-4.6mpa
-
Tolerance range of pressure switch:
-
1.45-14.5PSI/0.01-0.1mpa
-
Contact capacity:
-
AC240V,3A, AC120V,6A
-
Maximum burst pressure:
-
No breakdown and flashing in 1min at AC 1500V
-
Life cycle:
-
100000times
-
Application:
-
Protect and control high and low pressure
-
Types:
-
Thread,plug,capillary,copper pipe,wire
-
Sensor:
-
sealed stainless steel sensor
-
contact structure:
-
SPST or SPDT
-
Certification:
-
CE,UL
