Quick Details
-
Brand:
-
CHSUX
-
Application:
-
space launcher, microwave devices
-
Color:
-
Black+Copper
-
Material:
-
See the manual for details
-
Product name:
-
RF Connectors
-
Model:
-
BIB-JHD
-
Gender:
-
Male
-
Connector type:
-
Male Terminals
-
Function:
-
Connector Cap
Quick Details
-
Model Number:
-
BIB-JHD
-
Type:
-
Other, BIB RF Connectors
-
Place of Origin:
-
Guangdong, China
-
Brand:
-
CHSUX
-
Application:
-
space launcher, microwave devices
-
Color:
-
Black+Copper
-
Material:
-
See the manual for details
-
Product name:
-
RF Connectors
-
Model:
-
BIB-JHD
-
Gender:
-
Male
-
Connector type:
-
Male Terminals
-
Function:
-
Connector Cap
Product Description
|
Type:
|
BIB Series
|
|
Temperature Range:
|
- 40 ~ +125℃
|
|
Impedance:
|
50Ω
|
|
Frequency Range:
|
0-4GHz
|
|
Withstand Voltage:
|
≥ 1000V
|
|
Rate current:
|
≥ 5A
|
|
Contact Resistance:
|
Inner Conductor: ≤ 5mΩ
|
|
Insulation Resistance:
|
≥ 5000MΩ
|
|
Peak Transmission Power:
|
100W @ 2.7GHz @ 85℃
|
|
Voltage Standing Wave Ratio(VSWR):
|
≤ 1.15 (DC - 3GHz)
|
|
|
≤ 1.25 (3 - 4GHz)
|
|
Usage:
|
Communication equipment, microwave devices
|
|
Duaribity:
|
≥ 500 times
|
|
Contact Pressure:
|
≥ 1N
|
|
Axial Tolerance:
|
± 1.0mm
|
|
Radial Tolerance:
|
± 0.5mm
|
|
Plug and Seat Fit Insert Loss dB:
|
≤ 0.2dB @2GHz; 0.4 dB @ 4 GHZ or less
|
|
Materials and Coating:
|
|
SMA Series
|
||
|
Piece Part:
|
Base Material
|
Plating
|
||
|
Terminal:
|
Beryllium Bronze QBe2
|
D. Ni1.27 Au0.. 38 (effective contact area)
|
||
|
Insulator:
|
Fluoropolymer
|
|
||
Related Products
Packing&Shipping
Inner package:
Precision RF connectors will be packed with tray or PE bags each pcs per bag in Standard Export Carton, or if you have your own packing demand, please tell us, we will pack them as your requirement.
