Industry application
:
matching with pharmaceutical machine, filling machine; different liquids filling like cosmetic, food, beverage and oral liquid.
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Shenchen
-
Model Number:
-
KF300 Plus/KT15
-
Place of Origin:
-
Hebei, China
-
Pump name:
-
KF300 Plus
-
Pump head:
-
KT15
-
Flow rate:
-
0.0033-326.55mL/min
-
Speed range:
-
1-350rpm
-
Housing material:
-
304 Stainless Steel
Quick Details
-
Application:
-
Food and Beverage Industry, Industrial Utilities
-
Pressure:
-
Low Pressure
-
Voltage:
-
240V/110V
-
Brand Name:
-
Shenchen
-
Model Number:
-
KF300 Plus/KT15
-
Place of Origin:
-
Hebei, China
-
Pump name:
-
KF300 Plus
-
Pump head:
-
KT15
-
Flow rate:
-
0.0033-326.55mL/min
-
Speed range:
-
1-350rpm
-
Housing material:
-
304 Stainless Steel
Product Description
Introduction
KF300 Plus
series are type of split intelligent filling system with high precision and low pulsation. KF300 Plus is driven by servo motor and consists of one controller and 32 filling units. It is suitable for liquids filling with high precision in laboratory. You can add or delete filling units according to your different requests.
OSD
Product Parameters
|
Speed range
|
1-350rpm
|
|
Dispensing volume range
|
0.01-9999.99ml
|
|
Dispensing time
|
0.1-9999.99s
|
|
Pause time
|
0.1-9999.99s
|
|
Volume resolution
|
0.01ml
|
|
Time resolution
|
0.01s
|
|
Copy numbers
|
1-9999 times, setting "0" means unlimited
|
|
Back suction angle
|
0-3600°
|
|
Dispensing accuracy
|
＜± 0.5%
|
|
Filling accuracy
|
1-32 units
|
|
Display
|
4.3 inch industrial grade true color LCD screen
|
|
Control method
|
Touch screen and mechanical keypad
|
|
Start/stop,direction
|
Passive switch signal, such as foot pedal
Active switch signal: 5V-24V
|
|
Output interface
|
Output motor working status(open-collector output)
|
|
Keypad lifetime
|
300,000 times
|
|
Power supply
|
AC 100V-240V (50Hz/60Hz)
|
|
Communication interface
|
RS485 support Modbus protocol (RTU mode)
|
|
Condition temperature
|
0-40℃
|
|
Relative humidity
|
＜80%
|
Filling Volume Reference (Media is water)
|
Drive
|
Pump
Head
|
Tubing
|
mL/r
|
Filling
Volume(s)
|
Filling
Time(s)
|
Accuracy
(±%）
|
Output
(pcs/min)
|
Motor Speed
(rpm)
|
|
KF300
Plus
|
KT15
|
14#
|
0.156
|
1
|
1.5
|
1
|
24
|
256.41
|
|
|
|
14#
|
0.156
|
2
|
3
|
0.5
|
15
|
314.69
|
|
|
|
19#
|
0.286
|
3
|
2
|
0.8
|
20
|
314.47
|
|
|
|
16#
|
0.477
|
5
|
2
|
0.8
|
20
|
225.08
|
|
|
|
25#
|
0.933
|
7
|
2
|
1
|
20
|
241.94
|
