Quick Details
-
Dimensions(L*W*H):
-
12100*2500*2520mm
-
Weight:
-
12000KG/1300KG/14000KG/15000KG
-
Warranty:
-
one year
-
Certification:
-
ISO9001:2008 CE
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Printing colors:
-
1-10 colors
-
Diamter of pring cylinder:
-
100-320mm
-
diameter of unwind/rewind:
-
600mm
-
Max.printing width:
-
600-1200mm
-
Machine printing speed:
-
130m/min
-
Register precision:
-
±0.12mm
-
Max.printing speed:
-
140m/min
-
Drying method:
-
Electric heating and steam heating or oil heating
-
Overall dimension:
-
12100*2500*2520mm
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
Guowei
-
Voltage:
-
380V
-
Dimensions(L*W*H):
-
12100*2500*2520mm
-
Weight:
-
12000KG/1300KG/14000KG/15000KG
-
Warranty:
-
one year
-
Certification:
-
ISO9001:2008 CE
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Printing colors:
-
1-10 colors
-
Diamter of pring cylinder:
-
100-320mm
-
diameter of unwind/rewind:
-
600mm
-
Max.printing width:
-
600-1200mm
-
Machine printing speed:
-
130m/min
-
Register precision:
-
±0.12mm
-
Max.printing speed:
-
140m/min
-
Drying method:
-
Electric heating and steam heating or oil heating
-
Overall dimension:
-
12100*2500*2520mm
| Printing Material | BOPP,PET,PVC,PE,NY,(Paper) |
| Model | 850,1000,1100,1200-1600mm |
| Printing colors | 1-15 |
| Plate cylinder | 100-320mm |
| Mechanical speed | 150m/min |
| Max.printing speed | 130m/min |
| Register precision | ±0.10mm |
| Unwinding/rewinding dia. | 600mm |
| Optional functions | Pneumatic turret design |
Wenzhou Guowei Printing Machinery Co.ltd established in 1998,in Wenzhou Ruian city,Zhejiang Privice,China. We are a manufacturer specializing in the production of Rotogravure Printing Machine ,Laminating Machine , Slitting Machine and Flexible packaging machines over 20 years. Good quality and excellent performance in printing crafts with Good after-sales service is our superiority. Taking every project as unique,customized manufacturing and service total solutions is our production principle. Choose us, choose best machine for you!
