Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
G.Craftsman
-
Model Number:
-
GA-PM1X20D-M6S
-
Warranty:
-
2 Year
-
Video Compression Format:
-
H.265+
-
Material:
-
Metal Housing
-
Waterproof:
-
IP67
-
Resolution:
-
3072*2048
-
WDR:
-
WDR, HDR
-
Lens:
-
4.7-94mm
-
Audio:
-
Two-way Audio
-
SD Card Slot:
-
Max 256GB
-
Night vision:
-
IR Distance 100-120M
-
Power Supply:
-
POE/DC12V
Quick Details
-
Special Features:
-
Human Motion Tracking, NIGHT VISION, Vandal-proof, Motion Detection, Waterproof / Weatherproof, Built-in Siren, PAN-TILT, Two-way Audio, Humanoid Detection
-
Function:
-
Two-way Audio, PAN-TILT, Alarm I/O, RESET, Built-in Mic, NIGHT VISION, Waterproof / Weatherproof, Wide Angle, Built-in Siren, Vandal-proof
-
Customized support:
-
Online technical support, Customized logo, Software reengineering, OEM, ODM
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
G.Craftsman
-
Model Number:
-
GA-PM1X20D-M6S
-
Warranty:
-
2 Year
-
Video Compression Format:
-
H.265+
-
Material:
-
Metal Housing
-
Waterproof:
-
IP67
-
Resolution:
-
3072*2048
-
WDR:
-
WDR, HDR
-
Lens:
-
4.7-94mm
-
Audio:
-
Two-way Audio
-
SD Card Slot:
-
Max 256GB
-
Night vision:
-
IR Distance 100-120M
-
Power Supply:
-
POE/DC12V
More Hot Sale Products
Product Description
Pan & Tilt Setting
With a sophisticated pan/tilt mechanism, Gcraftsman PTZ Camera provides fast, precise movement with endless 360° pan and 105° tilt. The Control Speed is 0.01°~60° /S.
20X Optical Zoom
Gcraftsman 20X PTZ Camera is designed to extend user’s reach to the max with the fast 4.7~94mm@F1.5 ~F4.0 lens. The 20X optical zoom allows the user to zoom up to distant subjects while still maintaining the clarity, delivering high quality video over the entire zoom range.
PTZ Auto Tracking
Once PTZ Auto Tracking function enabled, Gcraftsman PTZ cameras could leverage motor mechanism to perform Pan/Tilt/Zoom to track the moving human automatically and adjust zoom status flexibly according to the object distance with the powerful optical zoom capability.
Clear Two-Way Audio
Built-in microphone & speaker allow you to listen and talk to whoever the camera catches in real time clearly, G.Craftsman advanced echo canceller technology is able to transmit HQ sounds without noise
AI Smart Analytics
G.Craftsman AI Camera can intelligently filter objects to focus on human and vehicle detection, which greatly enhances the monitoring efficiency and benefits the large population related industries such as public security, access control and business management.
Smart Motion Detection
The Smart Motion Detection function enables the user to monitor specified area clearly in a timely manner. When there is motion detected in a target area, G.Craftsman Camera will give an alerts by email /APP Push for the objects automatically.
Starlight Ultra Low-light
G.Craftsman adopts HD Sony Starvis Sensor, which is able to deliver high detailed color images even in the low light environments reaching 0.001Lux (Color) or 0Lux (B/W), and near infrared light environments without any supplementary lighting.
120dB Super WDR
Sensor-based WDR technology allows the camera to record greater scene details with true color reproduction even under the extreme back light and high contrast conditions.
RTMP
G.Craftsman camera supports RTMP streaming live to enrich user experience. The streaming media services such as Twitch, YouTube,Facebook Live and the live platforms such as Dacast, Ant Media and Wowza can receive RTMP streaming.
IP67 Waterproof
Supporting IP67-rated weather-proof, which are the leading level of the industry, the G.Craftsman Network Camera is well protected against rainy and foggy weather to ensure the performance.
Better in Details
Revolutionary IR Performance
The IR LEDs technology has been upgraded to provide videos with a viewing range of 100m~120m. 6pcs IR Array can display a sharp B&W image at night, 4pcs Warmlights can display a colorful night vision image based on AI function.
Unique Structure Design
Aluminum alloy housing has a good effets on anti-surging and anti-corrosion. The large space bracket with side-holes is easy for built-in power supply and maintenance. Also, The cable with Multi-functional outputs is able to meet projects' various applications
Packing & Delivery
Quality camera and all of the accessories are well-packed with protective mat in the camera box. G.Craftsman uses h
ard & thick cartons with cornor pads to protect the cameras, especially the
vibration test before shipment can ensure the goods arrive there in good condition.
Product Parameters
|
Camera
|
|
|
|
|
|||
|
lmage Sensor
|
SONY IMX 335 CMOS
|
|
|
|
|||
|
Effective Pixels
|
6MP 3072*2048
|
|
|
|
|||
|
Electronic Shutter
|
AUTO, 1/25s ~ 1/100000s
|
|
|
|
|||
|
Min. lllumination
|
Color: 0.005Lux@F1.6; B/W: 0Lux with LED on
|
|
|
|
|||
|
Day/Night
|
Day/Night/Auto/Customize/Schedule
|
|
|
|
|||
|
Image Enhancement
|
BLC, HLC, 2D/3D DNR
|
|
|
|
|||
|
WDR
|
WDR,HDR
|
|
|
|
|||
|
Image Settings
|
Rotate, Mirror, Privacy Mask, Saturation, Brightness, Contrast, Sharpness, Gain, White Balance adjustable by client software or web browser
|
|
|
|
|||
|
Defog
|
Yes
|
|
|
|
|||
|
Encode
|
|
|
|
|
|||
|
Video Compression
|
H.265+/H.265/H.264 video encode，Support Bitrate 0.1M~8Mpbs;Support Frame rate 1~30 Fps/s；
|
|
|
|
|||
|
Main Stream
|
25FPS(3072x2048),30FPS(2592×1944,2560×1440,2304×1296,2048x1536), 60FPS(1920×1080,960P,720P,D1)
|
|
|
|
|||
|
Sub Stream
|
30FPS (720×480,D1,VGA,640×360)
|
|
|
|
|||
|
Video Bit Rate
|
512Kbps - 6Mbps, VBR/CBR
|
|
|
|
|||
|
Full Function
|
Audio I/O, Alarm I/O, BNC,Reset Button on Cable
|
|
|
|
|||
|
IR Led
|
|
|
|
|
|||
|
LED Type
|
6pcs IR Array +4pcs Warmlight (10pcs Pure IR Array/ 10pcs Pure Warmlight Optional)
|
|
|
|
|||
|
LED Distance
|
Up to 100-120M
|
|
|
|
|||
|
Lens
|
|
|
|
|
|||
|
Focal Length
|
4.7~94mm AF Lens
|
|
|
|
|||
|
Zoom
|
20x Optical Zoom
|
|
|
|
|||
|
PTZ
|
|
|
|
|
|||
|
Pan/Tilt Range
|
P:0-360°(60°/S) ; T:-15°-90° (60°/S);
|
|
|
|
|||
|
Preset Point
|
256
|
|
|
|
|||
|
A-B Scanning
|
Support 8 groups
|
|
|
|
|||
|
Auto Cruisig
|
Support 8 groups patrol
|
|
|
|
|||
|
Pattern Scanning
|
Support 4 groups patrol
|
|
|
|
|||
|
Power on Action
|
Preset/Scan/ Cruise/Pattern
|
|
|
|
|||
|
Power-off Recovery
|
Support
|
|
|
|
|||
|
Network
|
|
|
|
|
|||
|
Network Storage
|
NFS /NAS /FTP(Photo)
|
|
|
|
|||
|
Protocol
|
Supports network protocols such as HTTP/RTSP/DHCP/NTP/ONVIF/P2P/RTMP and multiple NVR docking protocols
|
|
|
|
|||
|
P2P Cloud Service
|
Yes
|
|
|
|
|||
|
System
|
|
|
|
|
|||
|
Motion Detection
|
Yes
|
|
|
|
|||
|
Event Trigger Event Action
|
FTP Upload(Only Photo), SMTP Upload, SD Card Record,Alarm Server Center Upload
|
|
|
|
|||
|
Intelligent Analysis
|
Human Shape, Vehicle Type Detection
|
|
|
|
|||
|
System Compatibility
|
Onvif (Profile S)
|
|
|
|
|||
|
Web Client Language
|
English, Russian, German, Italian,Turkish, Polish, Korean, Japanese,Slovenian,Traditional Chinese, Simplified Chinese etc.
|
|
|
|
|||
|
General
|
|
|
|
|
|||
|
Protection Level
|
Full Metal, IP67
|
|
|
|
|||
|
Built-in SD Card Slot
|
Yes, Max 256GB
|
|
|
|
|||
|
Working Temperature
|
-40℃~60℃ (-40 °F to 140 °F)
|
|
|
|
|||
|
Humidity Power Supply
|
0~95%(Non-condensing)
|
|
|
|
|||
|
Power Connector
|
POE/ DC12V
|
|
|
|
|||
