- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
MODO
-
Model Number:
-
MSS
-
Place of Origin:
-
Hebei, China
-
Horsepower:
-
4hp-420hp/As customer request
-
Power Source:
-
Hydraulic / Electric
-
Cable Length:
-
8m/10m/Customer Required
-
Outlet Size:
-
2inch-16inch/As customer request
-
Power:
-
3kw-315kw/As customer request
-
motor:
-
As customer request
-
Theory:
-
Centrifugal Pump
-
Material:
-
Cr27 ; stainless steel
-
Max. Solid Size:
-
10-66mm
-
Color:
-
As customer request
-
Temperature:
-
Max.110℃
-
Pump Type:
-
Vertical
-
Phase:
-
3
-
Certification:
-
CE / ISO45001:2018 / ISO9001:2015 / ISO14001:2015
Quick Details
-
Application:
-
Industrial Utilities, Metal and Equipment Manufacturers, Mining industry, Washing and Cleaning, Sand dredging
-
Pressure:
-
As customer request
-
Voltage:
-
220V/380V/400V/415V/440V/600V/1140V
-
Warranty:
-
1 year
-
Brand Name:
-
MODO
-
Model Number:
-
MSS
-
Place of Origin:
-
Hebei, China
-
Horsepower:
-
4hp-420hp/As customer request
-
Power Source:
-
Hydraulic / Electric
-
Cable Length:
-
8m/10m/Customer Required
-
Outlet Size:
-
2inch-16inch/As customer request
-
Power:
-
3kw-315kw/As customer request
-
motor:
-
As customer request
-
Theory:
-
Centrifugal Pump
-
Material:
-
Cr27 ; stainless steel
-
Max. Solid Size:
-
10-66mm
-
Color:
-
As customer request
-
Temperature:
-
Max.110℃
-
Pump Type:
-
Vertical
-
Phase:
-
3
-
Certification:
-
CE / ISO45001:2018 / ISO9001:2015 / ISO14001:2015
--Products Description--
MSS submersible slurry pump
MSS Submersible Slurry Pump series are heavey duty
,electro-submersible slurry pumps designed to handle a
wide range of slurries and abrasive particles in submersible applications in mining and industry.
MSS pumps feature a rugged construction using the highest quality materials to ensure reliable performance and excellent service life. The high quality electric motors incorporate multiple protection features to detect the ingress of water or excessive temperatures to shut off the pump and prevent damage.
Pumps are available in 72 different models in sizes ranging from 80mm to 400mm (3.15-16 inches) discharge and are capable of flow rates from 23 to 2400 cubic meters per hour (100-10560USGPM) and heads up to 64 meters (210ft).Pumps can pass solids up to 60mm (2.4 inches) in diameter enabling them to transfer dense slurries with large abrasive particles.
MSS pumps feature a rugged construction using the highest quality materials to ensure reliable performance and excellent service life. The high quality electric motors incorporate multiple protection features to detect the ingress of water or excessive temperatures to shut off the pump and prevent damage.
Pumps are available in 72 different models in sizes ranging from 80mm to 400mm (3.15-16 inches) discharge and are capable of flow rates from 23 to 2400 cubic meters per hour (100-10560USGPM) and heads up to 64 meters (210ft).Pumps can pass solids up to 60mm (2.4 inches) in diameter enabling them to transfer dense slurries with large abrasive particles.
--Details Images--
--Product Paramenters--
|
PUMP SPECIFICATIONS
|
|
|
|
Usage
|
Slurry, Water & Sewage
|
|
|
Type
|
MSS Submersible Slurry Pump
|
|
|
Capacity
|
Up to 2400 m3/hr (666L/S)
|
|
|
Head
|
Up to 60 m ( 196 feet )
|
|
|
Speed
|
Up to 1480 rpm
|
|
|
Discharge
|
80-400mm (3.15’’ up to 16’’)
|
|
|
Temperature
|
Max.: 80℃
|
|
|
Drive
|
Hydraulic or Electric
|
|
|
Agitator
|
27% Chrome White Iron or 316 Stainless Steel / Duplex1
|
|
|
Model
|
Outlet Dia. (mm)
|
Capacity (m³/h)
|
Head (m)
|
Power (Kw)
|
Speed (r/min)
|
Max.Dia.of Solid (mm)
|
Pump Weight (kg)
|
|
SS45-15-5.5
|
80
|
45
|
15
|
5.5
|
1460
|
13
|
100
|
|
SS15-20-5.5
|
80
|
15
|
20
|
5.5
|
1460
|
13
|
100
|
|
SS30-30-7.5
|
80
|
30
|
30
|
7.5
|
1460
|
13
|
114
|
|
SS50-26-11
|
80
|
50
|
26
|
11
|
1460
|
13
|
165
|
|
SS75-25-15
|
100
|
75
|
25
|
15
|
1460
|
13
|
220
|
|
SS150-18-18.5
|
150
|
150
|
18
|
18.5
|
980
|
32
|
550
|
|
SS200-12-22
|
150
|
200
|
15
|
22
|
980
|
45
|
580
|
|
SS60-46-30
|
150
|
60
|
46
|
30
|
980
|
21
|
700
|
|
SS150-30-30
|
150
|
150
|
30
|
30
|
980
|
21
|
550
|
|
SS300-20-37
|
200
|
300
|
20
|
37
|
980
|
28
|
775
|
|
SS200-30-45
|
150
|
200
|
30
|
45
|
980
|
36
|
1000
|
|
SS500-15-45
|
250
|
500
|
15
|
45
|
980
|
46
|
1100
|
|
SS250-35-55
|
150
|
250
|
35
|
55
|
980
|
36
|
1140
|
|
SS600-15-55
|
250
|
600
|
15
|
55
|
980
|
46
|
1140
|
|
SS350-35-75
|
200
|
350
|
35
|
75
|
980
|
28
|
1550
|
|
SS500-20-75
|
200
|
500
|
20
|
75
|
980
|
25
|
1550
|
|
SS200-60-90
|
150
|
200
|
60
|
90
|
980
|
14
|
1550
|
|
SS400-40-90
|
200
|
400
|
40
|
90
|
980
|
28
|
1550
|
|
SS600-30-110
|
200
|
600
|
30
|
110
|
980
|
28
|
1970
|
|
SS1000-18-110
|
300
|
1000
|
18
|
110
|
980
|
50
|
1970
|
|
SS500-45-132
|
200
|
500
|
45
|
132
|
980
|
28
|
2000
|
|
SS1000-22-132
|
300
|
1000
|
22
|
132
|
980
|
50
|
2000
|
|
SS650-52-160
|
200
|
650
|
52
|
160
|
980
|
28
|
2650
|
|
SS780-50-185
|
300
|
780
|
50
|
185
|
980
|
38
|
3330
|
|
SS800-55-220
|
300
|
800
|
55
|
220
|
980
|
38
|
3400
|
|
SS1250-35-220
|
350
|
1250
|
35
|
220
|
980
|
45
|
3400
|
|
SS1750-30-250
|
350
|
1750
|
30
|
250
|
980
|
55
|
3500
|
|
SS2000-35-315
|
400
|
2000
|
35
|
315
|
980
|
60
|
3700
|
