Quick Details
-
Size(mm):
-
1400(L)*200(W)*980(H) standard
-
Cabinet material:
-
SUS304 stainless steel
-
Material thickness(mm):
-
1.5
-
Application environment:
-
Indoor
-
Gate material:
-
Plexiglass
-
Gate dimension(mm):
-
280(L)*550(H)*8(T)
-
Failure-free operation:
-
≥5,000,000 cycles
-
Power supply:
-
AC220V±, 50Hz
-
Operation temperature:
-
-30℃~60℃
-
Warranty:
-
1 Year
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Zecheng
-
Model Number:
-
ZC-B109
-
Size(mm):
-
1400(L)*200(W)*980(H) standard
-
Cabinet material:
-
SUS304 stainless steel
-
Material thickness(mm):
-
1.5
-
Application environment:
-
Indoor
-
Gate material:
-
Plexiglass
-
Gate dimension(mm):
-
280(L)*550(H)*8(T)
-
Failure-free operation:
-
≥5,000,000 cycles
-
Power supply:
-
AC220V±, 50Hz
-
Operation temperature:
-
-30℃~60℃
-
Warranty:
-
1 Year
Product Description
Product Paramenters
|
Physical dimensions (mm):
|
1400(Length) * 200(width ) * 980 (height) customized optional
|
|
Cabinet material :
|
SUS304 stainless steel; Surface brushed treatment
|
|
Material thickness (mm):
|
1.5
|
|
Width of passage (mm):
|
600（standard passageway); 700 (wide passageway)
|
|
Gate material :
|
Plexiglass
|
|
Gate dimension (mm):
|
280(Length)*550(Height)*8(Thickness)
|
|
Gate open and close responding time:
|
＜0.1 seconds
|
|
Gate running speed:
|
Rad/s (adjustable)
|
|
Average times of failure-free operation :
|
5,000,000 cycles
|
|
Passageway target detection:
|
4 groups of active infrared detectors
|
|
Pass speed:
|
≥50 /minutes (Normally closed type)
|
|
Application environment
|
Indoor/outdoor
|
|
Operation temperature:
|
- 30°C~60°C
|
|
Operation humidity :
|
90%, none condensation
|
|
Power supply:
|
AC220V±，50Hz
|
|
Average power consumption (W):
|
60
|
