- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
JUBO
-
Model Number:
-
JBRD-800FD-P
-
Transmission frequency:
-
76~81GHz
-
Application scope:
-
Strong corrosive liquid, stirring, water vapor condensation,etc
-
Measurement range:
-
120m
-
Output signal:
-
4-20mA/RS-485
-
Medium temperature:
-
-40℃~100℃
-
Process pressure:
-
-0.1~1MPa
-
Beam angle:
-
3°
-
Protection level:
-
IP68
-
Antenna type:
-
Lens antenna
-
Shell material:
-
Aluminum casting/stainless steel
Quick Details
-
Grade:
-
Industrial
-
Warranty:
-
1years
-
Place of Origin:
-
Hebei, China
-
Brand Name:
-
JUBO
-
Model Number:
-
JBRD-800FD-P
-
Transmission frequency:
-
76~81GHz
-
Application scope:
-
Strong corrosive liquid, stirring, water vapor condensation,etc
-
Measurement range:
-
120m
-
Output signal:
-
4-20mA/RS-485
-
Medium temperature:
-
-40℃~100℃
-
Process pressure:
-
-0.1~1MPa
-
Beam angle:
-
3°
-
Protection level:
-
IP68
-
Antenna type:
-
Lens antenna
-
Shell material:
-
Aluminum casting/stainless steel
Power Industry
The main application areas include desulfurization, lubricating oil, mud, raw coal bunker, fuel bunker, etc.
The main application areas include desulfurization, lubricating oil, mud, raw coal bunker, fuel bunker, etc.
Coal industry
The main application areas include raw coal, clean coal, cinder, coal-containing sewage in coal washing plants, etc.
The main application areas include raw coal, clean coal, cinder, coal-containing sewage in coal washing plants, etc.
Cement industry
The main application areas include slag storage silos, raw meal homogenization silos, clinker silos, cement silos, etc.
The main application areas include slag storage silos, raw meal homogenization silos, clinker silos, cement silos, etc.
Metallurgical industry
The main application areas in the metallurgical industry include iron ore, limestone raw materials, and raw coal bunkers in
steelmaking plants; carbon powder, aluminum ore, and coal powder in aluminum plants, etc.
The main application areas in the metallurgical industry include iron ore, limestone raw materials, and raw coal bunkers in
steelmaking plants; carbon powder, aluminum ore, and coal powder in aluminum plants, etc.
Petrochemical industry
The main application areas include crude oil, hydrogen tincture, waste oil, sludge in oil production plants, settling tanks,
sewage tanks, drilling mud tanks in oil fields, liquefied natural gas and condensed water in liquefied gas stations, oil storage
depots, gasoline in biodiesel plants, Diesel oil, tar, urea melt from compound fertilizer plants, ammonia water, various chemical
products from chemical plants, high temperature, high pressure and highly corrosive media, etc.
The main application areas include crude oil, hydrogen tincture, waste oil, sludge in oil production plants, settling tanks,
sewage tanks, drilling mud tanks in oil fields, liquefied natural gas and condensed water in liquefied gas stations, oil storage
depots, gasoline in biodiesel plants, Diesel oil, tar, urea melt from compound fertilizer plants, ammonia water, various chemical
products from chemical plants, high temperature, high pressure and highly corrosive media, etc.
Water conservancy industry
The main application areas include lakes, rivers, open channels, wetlands, shoals, tides, underground water pipe networks, ditches
containing a large amount of floating matter and sediment, places where a large amount of aquatic plants are produced, and areas
prone to flash floods.
The main application areas include lakes, rivers, open channels, wetlands, shoals, tides, underground water pipe networks, ditches
containing a large amount of floating matter and sediment, places where a large amount of aquatic plants are produced, and areas
prone to flash floods.
|
Place of Origin
|
Hebei, China (Mainland)
|
|
Brand Name
|
JUBO
|
|
Model Number
|
JBRD-800-FD-P
|
|
Grade
|
Industrial
|
|
Application
|
Strong corrosive liquid, stirring, water vapor condensation,Etc
|
|
Medium temperature
|
-40°~100°
|
|
Measuring Range
|
120m
|
|
Beam Angle
|
3°
|
|
Type
|
Non-contact
|
|
Material
|
Stainless Steel/Aluminum alloy
|
|
Power supply
|
RS485:9-36V
4-20mA:12-36V
|
|
Output signal
|
two wire:4-20mA/Hart
four wire:4-20mA/Hart,RS485/Modbus
|
|
Measurement accuracy
|
±1mm
|
|
Installation method
|
Flange
|
|
Protection grade
|
IP68
|
|
Explosion proof level
|
Ex d ia IIC T6 Gb
|
Hebei Jubo Technology Co., Ltd. is an emerging automation technology enterprise specializing in the research and development, design, production, sales, and service of industrial intelligent instruments and meters. The company is located in the Zhongnan High tech Industrial Park of the Cangzhou Development Zone in the Bohai Rim Industrial Base, with developed land and sea transportation and superior geographical location.
Combining the advantages of talent and technology in Beijing Tianjin Hebei and the high-end equipment manufacturing industry in eastern Hebei, the company has successively established CNC machining centers, precision electronic manufacturing centers, and radar application research and development centers. After years of accumulation and development, the company has achieved a huge transformation from OEM manufacturing to independent development and manufacturing.
At present, the company's products with independent intellectual property rights include: radar level gauge, ultrasonic level gauge, magnetostrictive Level sensor and other product series. The comprehensive performance of the product has reached the international advanced level. In recent years, the company's products have been widely used in engineering fields such as petroleum, chemical, pharmaceutical, metallurgy, textile, machinery, heating, power supply, scientific research, and the environment, and are highly praised by customers! The company has always adhered to the concept of "honesty and trustworthiness, continuous improvement, service first, and customer first", adhering to the business philosophy and ideology of people-oriented and management as quality assurance, striving to create first-class products, first-class technology, first-class service, and first-class enterprise.
Q:What kind of products do you offer ?
A:We supply 80G level sensor, 26G level sensor,flow meter. Main market is European countries, American, The Middle East and Asia.Certificates are international ones.
Q:Could I get samples?
A:Yes,We have materials in stock to help you to get the samples as soon as we can.
Q:How about the quality of the products?
A:We have the certification of ISO,CE .We could send the certification test of our company to you.
Q:Could you provide me the shortest lead time?
A:We have materials in our stock,If you really need,you can tell us and we will try our best to satisfy you.
Q:Could I visit your factory?
A:Of course,If you need we will help you to visit our factory.
Q: How can I get the quotation or send my inquiry to?
A: Send your inquiry to us by the inquiry from on the right-side or the bottom of this page.
1. How to order?
2. In order to send you correct solution and best offer, please provide the following information when send inquiry,
A:We supply 80G level sensor, 26G level sensor,flow meter. Main market is European countries, American, The Middle East and Asia.Certificates are international ones.
Q:Could I get samples?
A:Yes,We have materials in stock to help you to get the samples as soon as we can.
Q:How about the quality of the products?
A:We have the certification of ISO,CE .We could send the certification test of our company to you.
Q:Could you provide me the shortest lead time?
A:We have materials in our stock,If you really need,you can tell us and we will try our best to satisfy you.
Q:Could I visit your factory?
A:Of course,If you need we will help you to visit our factory.
Q: How can I get the quotation or send my inquiry to?
A: Send your inquiry to us by the inquiry from on the right-side or the bottom of this page.
1. How to order?
2. In order to send you correct solution and best offer, please provide the following information when send inquiry,
Thanks !
3. What is the process medium? Water, oil or others.
4. Measure range: 0-35m or..?
5. Output signal:4-20mA, RS485 or..?
6. Require quantity?
Q: What is your normal delivery way?
A: Goods will be sent by DHL / FEDEX / UPS / EMS / TNT / or other proposed forwarders.
3. What is the process medium? Water, oil or others.
4. Measure range: 0-35m or..?
5. Output signal:4-20mA, RS485 or..?
6. Require quantity?
Q: What is your normal delivery way?
A: Goods will be sent by DHL / FEDEX / UPS / EMS / TNT / or other proposed forwarders.
