Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM/MOKO
-
Copper Thickness:
-
1oz
-
Min. Hole Size:
-
0.25mm
-
Min. Line Width:
-
0.1mm/4mi
-
Min. Line Spacing:
-
0.1mm/4mil
-
Surface Finishing:
-
HASL
-
Certificate:
-
ROSH. ISO9001
-
Solder mask:
-
RED/YE;LLOW/WHITE/BLACK
-
Material:
-
FR4,ALU,PI
-
Inner packing:
-
Vacuuam Packing
-
profiling punching:
-
Routing,V-CUT,Beveling
-
Testing:
-
Flying/E-testing tooling
-
Max Panel size:
-
500*500MM
Quick Details
-
Base Material:
-
FR-4
-
Board Thickness:
-
1.6mm
-
Model Number:
-
MK-PCB0213001
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
OEM/MOKO
-
Copper Thickness:
-
1oz
-
Min. Hole Size:
-
0.25mm
-
Min. Line Width:
-
0.1mm/4mi
-
Min. Line Spacing:
-
0.1mm/4mil
-
Surface Finishing:
-
HASL
-
Certificate:
-
ROSH. ISO9001
-
Solder mask:
-
RED/YE;LLOW/WHITE/BLACK
-
Material:
-
FR4,ALU,PI
-
Inner packing:
-
Vacuuam Packing
-
profiling punching:
-
Routing,V-CUT,Beveling
-
Testing:
-
Flying/E-testing tooling
-
Max Panel size:
-
500*500MM
Welcome To Moko
Our PCB board manufacture and PCB Assembly service.One-stop oem service
* PCB board file with parts list provided by customers
* PCB board made, circuit board parts purchased by us
* PCB board with parts assembled
* Electronic testing circuit board or PCBA
* Fast delivery, anti-static package
* RoHS Directive-compliant, lead-free
* One stop service for PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly,test, packing and PCB delivery
Professional PCB&PCBA Manufacturer
1. Detailed Specification of PCB Manufacturing
|
1 |
layer |
1-18 layer |
|
|
2 |
Material |
FR-4,CEM-1,CEM-3,High TG,FR4 Halogen Free,FR-1,FR-2 |
|
|
3 |
Board thickness |
0.2mm-4mm |
|
|
4 |
Max.finished board side |
500*500mm |
|
|
5 |
Min.drilled hole size |
0.25mm |
|
|
6 |
min.line width |
010mm(4mil) |
|
|
7 |
min.line spacing |
0.10mm(4mil) |
|
|
8 |
Surface finish/treatment |
HALS/HALS lead free,Chemical tin,Chemical Gold, Immersion gold Immersion Silver/Gold,Osp,Gold Plating |
|
|
9 |
Copper thickness |
0.5-4.0oz |
|
|
10 |
Solder mask color |
green/black/white/red/blue/yellow |
|
|
11 |
Inner packing |
Vacuum packing,Plastic bag |
|
|
12 |
Outer packing |
standard carton packing |
|
|
13 |
Hole tolerance |
PTH: ± 0.076,NTPH: ± 0.05 |
|
|
14 |
Certificate |
ISO9001,ISO14001,ROHS,CQC |
|
|
15 |
profiling punching |
Routing,V-CUT,Beveling |
|
|
16. providing OEM service to all sorts of printed circuit board assembly |
|||
2.Detailed Terms for Pcb Assembly
Technical requirement:
1) Professional Surface-mounting and Through-hole soldering Technology
2) Various sizes like 1206,0805,0603 components SMT technology
3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.
4) PCB Board Assembly With CE,FCC,Rohs Approval
5) Nitrogen gas reflow soldering technology for SMT.
6) High Standard SMT&Solder Assembly Line
7) High density interconnected board placement technology capacity.
Quote requirement:
· Gerber file of the bare PCB board
· BOM (Bill of material) for assembly
· To short the lead time, please kindly advise us if there is any acceptable components substitution.
· Testing Guide & Test Fixtures if necessary
· Programming files & Programming tool if necessary
· Schematic if necessary
Orientronic PCB assembly Equipment:
· SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4
· Reflow Oven: FolunGwin FL-RX860
· Wave Soldering Machine: FolunGwin ADS300
· Automated Optical Inspection (AOI): Aleader ALD-H-350B
· Fully Automatic SMT Stencil Printer: FolunGwin Win-5
3.View of MOKO Factory
1)ROHS SMT WORKSHOP
2)Main products
3) What's service we can offer
