Key Features:
*Gelled electrolyte made by mixing sulfuric acid with silica fume.*High rate discharge performance due to tight assembly
technology
*Strong heat dissipation and wide operating temperature range
*Avoid acid mist being separated out , environment friendliness
*Efficient venting system release excessive gas automatically
Applications:
*EPS and UPS battery backup
*Solar and wind energy storage system
*Telecommunication Equipment
*Power plant and transmission system
*Signal system , emergency lighting system , security system
- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
OPzV 2V 2500Ah
-
Place of Origin:
-
Anhui, China, Jiangsu, China
-
Material:
-
High Pure Lead
-
Color:
-
Grey, Black, White etc
-
Product Name:
-
GEL Battery
-
Terminal:
-
Lead/Copper
-
OEM/ODM:
-
Acceptable
-
Capacity:
-
OPzV 2V 2500Ah
-
Weight:
-
140KG
Quick Details
-
Anode Material:
-
Other
-
Application:
-
Electric Power Systems, Solar Energy Storage Systems
-
Brand Name:
-
Sail Solar, Sail Solar Or OEM
-
Model Number:
-
OPzV 2V 2500Ah
-
Place of Origin:
-
Anhui, China, Jiangsu, China
-
Material:
-
High Pure Lead
-
Color:
-
Grey, Black, White etc
-
Product Name:
-
GEL Battery
-
Terminal:
-
Lead/Copper
-
OEM/ODM:
-
Acceptable
-
Capacity:
-
OPzV 2V 2500Ah
-
Weight:
-
140KG
Products Description
|
Rated Voltage
|
2V
|
|
Numbers of cells
|
6 Cells
|
|
Capacity
|
2500Ah@10hr-rate to 1.80V per cell @25°C
|
|
Weight
|
140kg
|
|
Internal Resistance
|
Approx. 0.35mΩ
|
|
Terminal
|
F10(M8)
|
|
Max. Discharge Current
|
10000A(5s)
|
|
Short Circuit Current
|
12500A
|
|
Max. Charging Current
|
500.0A
|
|
Reference Capacity
|
C240 3235AH
|
|
Design Life
|
20years
|
|
Float Charging Voltage
|
2.25V~2.3V @ 25°C, Temperature Compensation: -3mV/°C/Cell
|
|
Cycle Use Voltage
|
2.37 V~2.4V @ 25°C, Temperature Compensation: -4mV/°C/Cell
|
|
Operating Temperature Range
|
Discharge: -40°C~60°C, Charge: -20°C~50°C, Storage: -40°C~60°C
|
|
Normal Operating Temperature Range
|
25°C±5°C
|
|
Self Discharge
|
Less than 2% at 25°C per month
|
|
Container Material
|
A.B.S. UL94-HB, UL94-V0 Optional.
|
Our Factory
Certifications
Package and Delivery
Note：
The Above packing information contained in this web is subject to change without notice. We will offer wooden box packing with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests.
