Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YK
-
Dimensions(L*W*H):
-
840*700*1700 mm
-
Weight:
-
90 KG
-
Certification:
-
ce
-
Max. Print Area:
-
550*350 mm
-
Keywords1:
-
plane screen printer
-
Keywords 2:
-
flat silk printing machine for Paper Card
-
Keywords 3:
-
screen printing machine for paper
-
Application area:
-
wood, plastic, metal, glass, leather, cosmetics, ceramic, electronic
-
Product Name:
-
plane screen printer flat silk printing machine for Paper Card
-
Machine type:
-
vacuum System FLAT Silk Screen Printing Machine
-
Advantage:
-
Can be operated in manual and semi-auto mode
-
Lead Time:
-
7 DAYS AFTER PAYMENT
-
Package:
-
PLYWOOD CASE
-
Standards Certificate:
-
ISO-9001,CE
Quick Details
-
Condition:
-
New
-
Color & Page:
-
Multicolor
-
Voltage:
-
220v
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YK
-
Dimensions(L*W*H):
-
840*700*1700 mm
-
Weight:
-
90 KG
-
Certification:
-
ce
-
Max. Print Area:
-
550*350 mm
-
Keywords1:
-
plane screen printer
-
Keywords 2:
-
flat silk printing machine for Paper Card
-
Keywords 3:
-
screen printing machine for paper
-
Application area:
-
wood, plastic, metal, glass, leather, cosmetics, ceramic, electronic
-
Product Name:
-
plane screen printer flat silk printing machine for Paper Card
-
Machine type:
-
vacuum System FLAT Silk Screen Printing Machine
-
Advantage:
-
Can be operated in manual and semi-auto mode
-
Lead Time:
-
7 DAYS AFTER PAYMENT
-
Package:
-
PLYWOOD CASE
-
Standards Certificate:
-
ISO-9001,CE
Product Description
plane screen printer flat silk printing machine for Paper Card
Description:
This plane screen printer machine is electric type ,not pneumatic ,it is an electric, high-precision and high-efficiency flat screen printing machine, using original Japanese and Taiwan imported pneumatic components.
But if you need print on paper,film,pvc,or other thin and light product ,we can add vacuum table
to fix the paper during the printing,it can make objects stable .
Adaptation: This machine is suitable for printing PCB boards, silica gel, textiles, plastic buttons, PET, cardboard, nameplates,trademarks, IC boards, membrane switch circuits,
mobile phone lenses,
glass, LCD panels and signs and other flat materials.
Machine Advantage:
1.Double-column structure, stable printing, low vibration, high precision, accurate multi-color overprinting;
2.precision linear guide rails are used for the left and right sliding guide of the head;
3.double guide posts left and right screen clamp arms, and plate spacing adjustment device is installed at the same time, printing accuracy: ±0.02 MM, the operating speed can reach 1800 times per hour.
4.The printing mode is set to manual/semi-automatic/full-automatic three modes, and the indirect time of printing action can be digitally controlled.
5.The independently designed machine head lifting device makes it easy for ink scraping/oil return knife, screen loading and unloading and screen cleaning.
6.This machine adopts a complete package and is maintenance-free. It is safe and beautiful, easy to operate, and convenient to fetch, which greatly improves production efficiency.
screen printing machine for paper
Specification
|
Working Table size:
|
400*600 mm
|
|
Two-way fine-tuning size of the table
|
±10 mm
|
|
Max printing area
|
550*350 mm
|
|
Maximum screen frame size
|
500*700 mm
|
|
Scraper adjustment angle
|
0-45°
|
|
Maximum printing height
|
0-50 mm
|
|
Max. printing speed
|
1800 pcs/hour
|
|
Power voltage
|
220V 50-60MHZ/600W
|
|
Air pressure
|
0.4-0.6 MPA
|
|
Machine dimension
|
840*700*1700mm
|
|
Machine Weight
|
280 kg
|
Packing & Delivery
plane screen printer flat silk printing machine for Paper Card
plane screen printer
1.Selling Units:Single item
2.Total package size:
(L)980 x(W)930 x(H)1950 mm
3.Gross weight: 300 kg
4.Package Type:plywood case /wooden case ,as required
