model
|
QT68
|
|
|
|
brand
|
Caelus Automation
|
|
|
|
Standard adaptor door width
|
Single open 500mm~2100mm/Double open 500mm~1050mm
|
|
|
|
Door door form
|
Single open
|
Double open
|
|
|
Weight of door blade type
|
150kg×1
|
75kg×2
|
|
|
Standby power
|
＜ 5W(Single open without lock statu)
|
|
|
|
Opening rate
|
100~500mm/s （ Adjustable）
|
|
|
|
Speed as Closed
|
100~500mm/s （ Adjustable）
|
|
|
|
Time of opening
|
0~20s（Adjustable）
|
|
|
|
Operating ambient temperature
|
-30℃ -50℃
|
|
|
|
Anti-shear speed in place
|
0mm/s（ Safe and harmless）
|
|
|
|
Standard function
|
Infrared sensor,Push then open,Manual push-pull
|
Push then open
|
|
|
Standard function
|
Extended functions
|
|
Infrared sensor
When the human body is close to the door, it will open automatically, and the sensing distance range can be adjusted |
Mobile phone control
Accessible to remote modules, supporting diversified personality settings |
|
Push then open
Manually push the door, and the door motor immediately recognizes the opening signal and starts automatically |
Switch control
Support matching of various press switches, touch switches, foot switches, etc |
|
Manual push-pull
In case of power failure, the door can be opened/closed manually in an emergency |
Remote control
It can realize functions such as unlocking, locking, opening, closing, and arbitrary start and stop |
|
|
Access control system
Support password/card/fingerprint/face recognition and other devices to authorize door opening and clock in |
|
|
Voice control
Support smart voice box such as Xiaoai, Xiaodu, Huawei and Tmall Genie |
|
|
Caelus servo motor
|
Traditional automatic door
|
|
life
|
No reduction gearbox design, small motor wear and more Heavy protection, longer service life
|
The gears of the reduction box are very easy to wear and the maintenance cost is high. The motor has a limited number of times and a short service life.
|
|
Install
|
① Quick installation components, easy to install
② Self-learning and adapting to the best state when powered on status, fool-proof installation is easier
|
① The mechanical hardware structure is complex and the installation steps trouble
② The installation and debugging procedures are
cumbersome and technically difficult |
|
Energy saving
|
★Small mechanical friction
★ low loss
★low power ★ high energy efficiency |
★Mechanical friction is large
★ power and loss are high
★Low energy efficiency |
|
|
Caelus servo motor
|
Traditional automatic door
|
|
Safety
|
★Anti-pinch systemincluded
★High-performance power supply to prevent short circuit, overvoltage and overcurrent faults and eliminate hidden dangers |
Old-fashioned square wave control is insensitive and kinky Force driven, anti-pinch function may cause loss of control and injury.
|
|
Stablize
|
★ Vector control system, smooth operation
★ Tens of thousands of aging tests, low failure rate, 3 million+ of cycle operation without failure Adaptive and self-adjusting operating curve keeps the door in optimal operating condition.
|
① Old-fashioned square wave control has poor accuracy and is easy to Stuttering occurs
② Complex structure and many fault points
③Mechanical wear and long-term use are prone to transportation problems. line error, requiring frequent manual adjustment and maintenance |
|
Function
|
★ Supports rich personalized settings such as operating speed, door opening and closing time, etc.
★Supports free switching between automatic, inching, fully open, fully closed and other modes
|
The functional system is limited and backward, and the function settings are relatively Less, inconvenient to operate
|
