Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
6230*2365*3752 mm
-
Machine Weight:
-
8200 kg
-
Bucket capacity:
-
1.0 m³
-
Marketing Type:
-
Hot Product
-
Wheel base:
-
2250 mm
-
Loading lifting capacity:
-
2500 KG
-
Max. Digging depth:
-
4085mm
-
Min. Ground clearance:
-
300 mm
-
Breakout force:
-
38KN
-
Dumping height:
-
2650 mm
-
Rated power:
-
75KW / 100HP
-
Rated Load:
-
2.5 Ton
-
Tyre:
-
14-17.5 / 19.5L-24
-
Backhoe capacity:
-
0.3 m³
Quick Details
-
Engine Brand:
-
YUCHAI
-
Power:
-
75 KW
-
Brand Name:
-
LUGONG
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
6230*2365*3752 mm
-
Machine Weight:
-
8200 kg
-
Bucket capacity:
-
1.0 m³
-
Marketing Type:
-
Hot Product
-
Wheel base:
-
2250 mm
-
Loading lifting capacity:
-
2500 KG
-
Max. Digging depth:
-
4085mm
-
Min. Ground clearance:
-
300 mm
-
Breakout force:
-
38KN
-
Dumping height:
-
2650 mm
-
Rated power:
-
75KW / 100HP
-
Rated Load:
-
2.5 Ton
-
Tyre:
-
14-17.5 / 19.5L-24
-
Backhoe capacity:
-
0.3 m³
|
Main Parameters
|
|
Engine
|
|
||
|
Operating weight
|
8200 KG
|
Model
|
Yuchai YC4A105Z-T20
|
||
|
Length×Width×Height
|
6230*2365*3752 mm
|
Type
|
Turbocharging four-stroke
|
||
|
Wheel base
|
2250 mm
|
Cylinder-inner diameter*stroke
|
4-108×132
|
||
|
Min. Ground clearance
|
300 mm
|
Rated power
|
75KW / 100HP
|
||
|
Performance
|
|
Rated speed
|
2400r/min
|
||
|
Bucket capacity
|
1.0 m³
|
Min. fuel consumption
|
135 G/Kw.h
|
||
|
Breakout force
|
38 KN
|
Max. torque
|
400 N.m
|
||
|
Loading lifting capacity
|
2500 KG
|
Displacement
|
4.3L
|
||
|
Dumping height
|
2650 mm
|
Transmission system
|
|
||
|
Dumping reach
|
1025 mm
|
Torque converter
|
|
||
|
Loading cutting depth
|
52 mm
|
Model
|
YJ280
|
||
|
Backhoe capacity
|
0.3 m³
|
Type
|
Single-stage three elements
|
||
|
Max. Digging depth
|
4085 mm
|
Max. efficiency
|
84.4%
|
||
|
Digging slewing amgle
|
190°
|
Inlet pressure
|
0.4Mpa-0.55Mpa
|
||
|
Max. Tractive force
|
39 KN
|
Outlet pressure
|
1.2Mpa-1.5Mpa
|
||
|
Bucket digging force
|
46.5 KN
|
Cooling mode
|
Oil-cooling pressure circulation
|
||
