Quick Details
-
Model Number:
-
W-123
-
Dimension:
-
900*380*550mm
-
Storage:
-
Other
-
SNR:
-
50Hz-18KHz±3dB
-
Output Power:
-
LF 2*600W(RMS)2*2400W(PEAK)
-
Format:
-
NA
-
Type:
-
3-way line array system
-
Frequency Response:
-
50Hz-18KHz±3dB
-
Color:
-
Black
-
Power handling:
-
400W(RMS)1600W(PEAK)
-
Nominal impedance:
-
8 ohm
-
Coverage:
-
110°H*10°V
-
Finsh:
-
polyurea coatings
-
LF section:
-
LF 2*12"(310mm) neodymium woofer 75mm(3in)coil
-
MF section:
-
1*10"(250mm) Mid-range 75mm(3in)coil
-
HF section:
-
2*3" neodymium compression driver with 75mm titanium diaphragm
Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
CVR
-
Model Number:
-
W-123
-
Dimension:
-
900*380*550mm
-
Storage:
-
Other
-
SNR:
-
50Hz-18KHz±3dB
-
Output Power:
-
LF 2*600W(RMS)2*2400W(PEAK)
-
Format:
-
NA
-
Type:
-
3-way line array system
-
Frequency Response:
-
50Hz-18KHz±3dB
-
Color:
-
Black
-
Power handling:
-
400W(RMS)1600W(PEAK)
-
Nominal impedance:
-
8 ohm
-
Coverage:
-
110°H*10°V
-
Finsh:
-
polyurea coatings
-
LF section:
-
LF 2*12"(310mm) neodymium woofer 75mm(3in)coil
-
MF section:
-
1*10"(250mm) Mid-range 75mm(3in)coil
-
HF section:
-
2*3" neodymium compression driver with 75mm titanium diaphragm
Product Description
|
Model
|
W-123
|
|
Type
|
Three-way line array system
|
|
Frequency Response
|
50Hz-18KHz±3dB
|
|
Power handling
|
LF 2x600W(RMS)2x2400W(PEAK)
MF 400W(RMS)1600W(PEAK) HF 240W(RMS)960W(PEAK) |
|
Sensitivity
|
LF 106dB(1W@1M)
MF 108dB(1W@1M) HF 111dB(1W@1M) |
|
Max SPL
|
LF 132dB(PEAK)
MF 136dB(PEAK) HF 139dB(PEAK) |
|
Drivers
|
LF 2×12"(310mm) neodymium woofer 75mm(3in)coil
MF 1×10"(250mm) woofer 75mm(3in)coil HF 2×3" neodymium compression driver with 75mm titanium diaphragm |
|
Nominal impedance
|
8 ohm
|
|
Coverage
|
110°H×10°V
|
|
Finish
|
Textured paint
|
|
Connectors
|
2×NL8MPR neutrik speakon
|
|
Enclosure
|
Birch Plywood
|
|
Dimensions
|
900×380×550mm(W×H×D)
|
|
Packing Dimensions
|
980×450×620mm(W×H×D)0.27cbm
|
|
Net weight
|
60kg
|
|
Gross weight
|
64kg
|
