Quick Details
-
Brand Name:
-
LIMING
-
Dimension(L*W*H):
-
5000*2790*3320 mm
-
Weight:
-
275000 KG
-
Product name:
-
VSI impact crusher
-
The Machines classification:
-
Building Stone Production Line
-
Capacity:
-
15-300 tph
-
Max. Feeding Size::
-
50 mm
-
Keyword:
-
Sand making machine
-
Processed Materials:
-
200 Kinds Materials
-
Crusher type:
-
Fine Crusher
-
Spare parts supply:
-
Anytime
-
After sale Service:
-
7*24hours
-
Test&Installation:
-
Under Enginees Guidence
Quick Details
-
Application:
-
quarry, mining, metallurgy
-
Capacity(t/h):
-
20-650tph
-
Place of Origin:
-
Henan, China
-
Brand Name:
-
LIMING
-
Dimension(L*W*H):
-
5000*2790*3320 mm
-
Weight:
-
275000 KG
-
Product name:
-
VSI impact crusher
-
The Machines classification:
-
Building Stone Production Line
-
Capacity:
-
15-300 tph
-
Max. Feeding Size::
-
50 mm
-
Keyword:
-
Sand making machine
-
Processed Materials:
-
200 Kinds Materials
-
Crusher type:
-
Fine Crusher
-
Spare parts supply:
-
Anytime
-
After sale Service:
-
7*24hours
-
Test&Installation:
-
Under Enginees Guidence
Silica sand vsi7611 sand making machinery stone crusher gravel river sand making plant for sale
VSI impact crusher Silica Sand Making Machine Vertical Shaft Impact Crusher is combined gravel plants customers over the years using traditional sand making machine problems encountered Professional R & D of a new sand shaping equipment.
You can put all kinds of rocks, gravel, river gravel, etc. made of compliance with various granularity construction sand, sandy uniform particle size, pressure high strength, widely used mechanism for sand and gravel, cement, refractory, metallurgical and other industries.
| Feedstock Size: | 30-50mm |
| Throughout: | 20-650T/h |
| Fields Of Application: | It is applied for sand quarry, mixing station, dry mortar, quartz sand, construction waste crushing and other industries, for highway, high-speed railway, high-rise buildings, municipal, concrete mixing station to provide quality sand aggregate. |
| Suitable Materials: | It is suitable for cobble stone, quartz, limestone, coal gangue, basalt, granite, and diabase. |
"Rock On Rock" And "Rock On Iron" Crushing
VSI impact crusher Silica Sand Making Machine Vertical Shaft Impact Crusher Price (also known as "Sand Maker") has two feed modes--"Rock On Rock" And "Rock On Iron" Crushing.
In order to meet the crushing demand of different customers, VSI Vertical-shaft Sand Maker takes two crushing methods--- "rock on rock" and "rock on iron"(which refer to "rock hitting rock" and "rock hitting iron" respectively). The material liner of "rock on rock" and counter block structure of "rock on iron" are designed specially according to the working condition of the sand-making machine, which greatly promotes the crushing ratio of the sand maker.
Parameter for Silica sand vsi7611 sand making machinery stone crusher gravel river sand making plant for sale
| Model | VSI5X7615 | VSI5X8522 | VSI5X9532 | VSI5X1145 | |
| Throughput capacity (t/h) | Center and Ring feeding | 150~280 | 240~380 | 350~540 | 500~640 |
| Center feeding | 70~140 | 120~190 | 180~280 | 250~360 | |
| Max. Feed Size (mm) | Soft material | <35 | <40 | <45 | <50 |
| Hard material | <30 | <35 | <40 | <45 | |
| Rotation speed (r/min) | 1700~1900 | 1500~1700 | 1300~1510 | 1100~1310 | |
| Power of double motor (KW) | 2×75 (100) | 2×110 (150) | 2×160 (220) | 2×220 (300) | |
| Overall dimension L×W×H (mm) | 4100×2330×2300 | 4140×2500×2700 | 4560×2600×2900 | 5000×2790×3320 | |
| Weight (t) | 8.6 | 11.8 | 17.5 | 27.5 | |
| Thin oil lubrication station | Power for double oil pump | 2×0.25(0.33) | |||
| Safety | To make sure the supply of the oil with double oil pump; stop working without oil or hydraulic pressure; temperature falls when the water cool;start the motor by heating it in winter | ||||
| Power for oil box heater | 2 KW | ||||
| Overall dimension L×W×H (mm) | 820×520×1270 | ||||
