Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HJS
-
Model Number:
-
N20
-
Torque:
-
3.8-3.9g.cm
-
Product Name:
-
N20 DC Motor
-
Size:
-
38*20.1*15.1mm
-
Weight:
-
17g
-
Nominal Voltage:
-
3.0V
-
Rated Current:
-
0.09A
-
Rated Power:
-
0.56W
-
Brush Type:
-
Electric Brush
-
OEM&ODM:
-
Acceptable
Quick Details
-
Speed(RPM):
-
18500-27500rpm
-
Continuous Current(A):
-
0.09-0.12A
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
HJS
-
Model Number:
-
N20
-
Torque:
-
3.8-3.9g.cm
-
Product Name:
-
N20 DC Motor
-
Size:
-
38*20.1*15.1mm
-
Weight:
-
17g
-
Nominal Voltage:
-
3.0V
-
Rated Current:
-
0.09A
-
Rated Power:
-
0.56W
-
Brush Type:
-
Electric Brush
-
OEM&ODM:
-
Acceptable
Product Paramenters
|
Model Number
|
|
|
JC-FFN20PA-12100
|
JC-FFN20PA-1565
|
||
|
Voltage
|
Operating Range(V)
|
|
2.0-5.0
|
1.5-4.5
|
||
|
|
Nominal(V)
|
|
3.0
|
3.0
|
||
|
Noload
|
Speed
|
r/min
|
18500
|
27500
|
||
|
|
Current
|
A
|
0.09
|
0.12
|
||
|
At Maximum Efficiency
|
Speed
|
r/min
|
14500
|
22600
|
||
|
|
Current
|
A
|
0.32
|
0.55
|
||
|
|
Torque
|
g.cm
|
3.8
|
3.9
|
||
|
|
|
mN.m
|
0.37
|
0.39
|
||
|
|
Output
|
W
|
0.56
|
0.9
|
||
|
Stall
|
Torque
|
g.cm
|
17.2
|
22
|
||
|
|
|
mN.m
|
1.69
|
2.16
|
||
|
|
Current
|
A
|
1.15
|
2.5
|
||
