Quick Details
-
Controller:
-
Curtis
-
Climbing Ability:
-
45%
-
size:
-
3030x1395x1990(without searching light)
-
Ground clearance:
-
415(16inch)
-
steering:
-
Single-stage rack and pinion steering system, automatic rocker
-
brake:
-
4-wheel hydraulic disc brake + hand brake
-
range:
-
40km
Quick Details
-
Motor:
-
two motor, DC 3.8KW and 5,3kw
-
Battery:
-
Trojan Battery
-
Max. Speed:
-
32km/h
-
Controller:
-
Curtis
-
Climbing Ability:
-
45%
-
size:
-
3030x1395x1990(without searching light)
-
Ground clearance:
-
415(16inch)
-
steering:
-
Single-stage rack and pinion steering system, automatic rocker
-
brake:
-
4-wheel hydraulic disc brake + hand brake
-
range:
-
40km
| Key Components | ||
| Battery | 8xT105(185Ah@5hr rate) | |
| Motor | Front 3.8KW Chinese motor+rear 5.3KW Chinese motor , DC | |
| Controller | 2XCurtis 1244 (400A@2minutes) | |
| Performance | ||
| Passenger capacity | 4 | |
| Range (loaded) based on flat road at a speed of 20km/h (km) * | >40 | |
| Max. speed @12.49:1 gear ratio | 32 | |
| Minimum turning radius (m) | 3.8(150inch) | |
| Max. climbing ability (loaded) @ 12.49:1 gear ratio | 45% | |
| Max. movement after brake at speed of 20km/h | ≤4m | |
| Max. loading weight | 320kgs(882lbs) | |
| Net weight | 840kgs | |
| Dimensions | ||
| Overall dimensions (mm) | 3030x1395x1990(without searching light) | |
| Min. ground clearance (mm) | 415(16inch) | |
| Wheelbase (mm) | 1660 | |
| Front wheel tread (mm) | 850 | |
| Rear wheel tread (mm) | 975 | |
| Detailed Configurations: ("S" stands for Standard configuration and "O" stands for Optional configuration) | |||
| Body and Frame | |||
| Chassis | Welded steel framework with phosphate+electro-coating treatment | S | |
| Roof frame | Steel frame with phosphate+powder coating treatment,black color | S | |
| Roof frame in camo color | O | ||
| Body | PP plastic front body + PP plastic rear body | S | |
| Color (front body, rear body and top) | camouflaged | S | |
| solid color | O | ||
| Roof | Fibreglass | S | |
| Canvas | O | ||
| Windshield | one-piece Organic glass | S | |
| Windshield, hinged | O | ||
| laminated windshield | O | ||
| laminated windshield with wiper | O | ||
| 3point seat belt | \ | O | |
| front bumper | Carbon steel, powder coating | S | |
| Front bumper in camo color | O | ||
| Metallic steel guard above front body | Carbon steel, powder coating | O | |
| Front basket | Carbon steel, powder coating | O | |
| Top basket | Carbon steel, powder coating | O | |
| Gun holder | \ | O | |
| Towing bar | \ | O | |
| Large Seats: | |||
| 1) backrest and cushion | Rebond seat + artificial leather | S | |
| backrest and cushion in camo | O | ||
| 2) armrest | Formed | S | |
| 3) plastic seat bottom | \ | S | |
| Formed seat&backrest vinyl | not include rear flip-flop seat | O | |
| Backrest cover in wood finish | \ | O | |
| Floor | rubber | S | |
| Dashboard in black plastic | battery power meter, power key, F/R switch, 4WD and 2WD switching button, winch switch; switch for searchlight (option) | S | |
| Dashboard in wood finish | \ | O | |
| Steering wheel in wood finish | \ | O | |
| Beverage holders | 4 cups drink holders | S | |
| Glove box | \ | S | |
| Glove box door (include two locks) in black plastic | 2 doors per set | O | |
| Glove box door (include two locks) in wood finish (inside and outside) | 2 doors per set | O | |
| Side trim | stainless steel | S | |
| Wheel fender in camo | \ | O | |
| Score card holder | on steering wheel | S | |
| Inner rear view mirror | One piece per cart in the middle of the windshield | O | |
| Side rear view mirror | Two pieces per cart | O | |
| Battery watering system,48V system | without water supply tool | O | |
| Manual Pump | water supply tool (other water supply tools are available) | O | |
| Electric system | |||
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 taillights( each combined 1 brake light with 1 turn signal), with DC-DC converter (converting from 48V to 12V), horn. | S | |
| Reversing alarm | \ | S | |
| Meter | speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator | O | |
| 12V accessory plug | to be mounted on the dashboard | O | |
| Winch | \ | O | |
| Searching light | 4pcs | O | |
| Hour meter | \ | O | |
| Charger | China origin, input 110V-240V~50Hz-60Hz, output 48V, 22A | S | |
| Steering and Suspension | |||
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function | S | |
| Brake system | 4-wheel hydraulic disc brake + hand brake | S | |
| Accelerator | Stepless speed change | S | |
| Front suspension system | Independent suspension | S | |
| Rear suspension system | Integrated rear end, leaf spring + shock absorber | S | |
| Driving mode | Front axle drive and rear axle drive (4x4) | S | |
| Gear ratio | 12.49:1 | S | |
| Wheel & Tyre | 12x7 Steel wheel, 24 x 8-12 tyre | S | |
| 12x7 steel Rim in camo color | O | ||
| 12x7 steel rim in black color | O | ||
| 12X7 steel wheel, 23x8.5-12 tyre | O | ||
| Standard Body Color (customized color if available, but extra cost should be paid) |
|
||||||||||||||||||||||||||||||||||||||||
| Standard Seat Color | White seat | Tan seat | All the color showed here is just for reference! | ||||||||||||||||||||||||||||||||||||||
|
|
|
The real color of the car may look different as | |||||||||||||||||||||||||||||||||||||||
| showed here! | |||||||||||||||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||||||||||||||
| Container loading qty | Disassembled | Assembled | |||||||||||||||||||||||||||||||||||||||
| Qty/20' | 4units | 1units | |||||||||||||||||||||||||||||||||||||||
| Qty/40' | 10units | 3units | |||||||||||||||||||||||||||||||||||||||
| Qty/40'HQ | 14units |
|
|||||||||||||||||||||||||||||||||||||||
