Quick Details
-
Brand Name:
-
Chinese Brand
-
Fork Length:
-
1070mm
-
Fork Width:
-
122mm
-
Overall Dimensions:
-
1070*122*50mm
-
Weight (KG):
-
4800 kg
-
Model number:
-
CPD35
-
Be self-possessed:
-
4800kg
-
Driving mode:
-
Mount type
-
Rated lifting weight:
-
3500kg
-
Load center distance:
-
500mm
-
Standard door lifting height:
-
3000mm
-
Total length to vertical face of fork:
-
2535mm
-
Fork size (thickness * width * length):
-
1070*122*50mm
-
Product Name:
-
lithium battery special vehicle
-
Tyre form:
-
pneumatic tire
Quick Details
-
Min. Lifting Height:
-
125mm
-
Warranty:
-
1 Year
-
Place of Origin:
-
China
-
Brand Name:
-
Chinese Brand
-
Fork Length:
-
1070mm
-
Fork Width:
-
122mm
-
Overall Dimensions:
-
1070*122*50mm
-
Weight (KG):
-
4800 kg
-
Model number:
-
CPD35
-
Be self-possessed:
-
4800kg
-
Driving mode:
-
Mount type
-
Rated lifting weight:
-
3500kg
-
Load center distance:
-
500mm
-
Standard door lifting height:
-
3000mm
-
Total length to vertical face of fork:
-
2535mm
-
Fork size (thickness * width * length):
-
1070*122*50mm
-
Product Name:
-
lithium battery special vehicle
-
Tyre form:
-
pneumatic tire
CPD35-AEY2 AE series 3.5 tons battery forklift From China Hangzhou For Sale
Product Description
Specification
Very long endurance
- The standard large-capacity lithium battery, which is 20% larger than the ordinary low-voltage 80V/404Ah lithium battery capacity, can meet the long life requirements
- Standard equipped with 317V automotive high voltage platform, the vehicle current is smaller, the heat loss is very low
Fast charging
- Standard super fast charge technology, can be charged 1C, the standard battery can be full in 1 hour.
- Compatible with electric vehicle charging pile function, charging more convenient.
Specification
| Product type number | CPD35-XY2G-SI24 | |
| Dynamic form | power-driven | |
| Operating form | Mount type | |
| Rated deadweight | Q (kg) | 3500 |
| Center distance of rated load | c (mm) | 500 |
| Be self-possessed | kg | 4800 |
| Tyre form | pneumatic tire | |
| Standard door lifting height | h3 (mm) | 3000 |
| Total length to vertical face of fork | l2 (mm) | 2535 |
| Overall width | b1(mm) | 1225 |
| Fork size (thickness * width * length) | s/e/l (mm) | 50/122/1070 |
| Maximum travel speed (full load/no load) | km/h | 21/21.5 |
| Maximum lifting speed (full load/no load) | mm/s | 445/525 |
| Descent speed (full load/no load) | mm/s | 415/450 |
| Service brake (mechanical, electronic, hydraulic) | Hydraulic type | |
| Parking brake (mechanical, electronic, hydraulic) | mechanical | |
| Travelling motor power, S2 60 min working | kW | 20AC |
| Standard battery voltage/capacity | V/Ah | 309/125 |
| Walk control form | AC | |
| Fittings provide pressure | MPa | 18.5 |
