Quick Details
-
Engine Brand:
-
YANMAR
-
Travel Speed:
-
0-14km/h
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Aowei
-
Dimension(L*W*H):
-
4850*2000*2750mm
-
Product name:
-
6 ton static single drum vibrator road roller
-
Name:
-
Hydraulic Vibratory Driving Road Roller
-
Drive Type:
-
Hydraulic Transmission
-
Vibration frequency:
-
46hz
-
Engine:
-
Diesel Engine
-
Engine Model:
-
YN4102Z
-
Steel wheel size:
-
1850mm*1200mm
-
Net weight:
-
8000kg
-
Starting mode:
-
Hand and electric
-
After Warranty Service:
-
Video technical support, Online support
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Video technical support, Online support
Quick Details
-
Type:
-
Vibratory Roller
-
Power:
-
76kw, 76kw
-
Weight:
-
8 Ton
-
Engine Brand:
-
YANMAR
-
Travel Speed:
-
0-14km/h
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Aowei
-
Dimension(L*W*H):
-
4850*2000*2750mm
-
Product name:
-
6 ton static single drum vibrator road roller
-
Name:
-
Hydraulic Vibratory Driving Road Roller
-
Drive Type:
-
Hydraulic Transmission
-
Vibration frequency:
-
46hz
-
Engine:
-
Diesel Engine
-
Engine Model:
-
YN4102Z
-
Steel wheel size:
-
1850mm*1200mm
-
Net weight:
-
8000kg
-
Starting mode:
-
Hand and electric
-
After Warranty Service:
-
Video technical support, Online support
-
Local Service Location:
-
None
-
After-sales Service Provided:
-
Video technical support, Online support
6 ton static single drum vibrator road roller
Our factory is integrated with production and sales road roller. We can customize the road roller according to customers' requirements (for example, change the engine or customized as other requirements).
Walk Behind Road Roller Technical Parameters:
|
Model |
AWR-0.5 |
|
Walk speed |
0-4km/h |
|
Gradeability |
30% |
|
Drive type |
Hydraulic drive |
|
Vibration control |
Automatic clutch |
|
Nominal amplitude |
0.5mm |
|
Vibration frequency |
70Hz |
|
Exciting force |
20KN |
|
Water tank |
20L |
|
Oil tank |
6L |
|
Engine model |
GX270/CF178F/CD180 |
|
Power |
9HP/6HP/7HP |
|
Steel wheel size |
φ450mm*600mm*2 |
|
Net weight |
560kg |
|
Starting mode |
Hand and electric |
Ride On Mini Road Roller Technical Parameters:
|
Model |
AWR-0.8 |
AWR-1.0 |
|
Walk speed |
0-5km/h |
0-6.5km/h |
|
Gradeability |
30% |
35% |
|
Drive type |
Hydraulic double drive |
Hydraulic double drive |
|
Vibration control |
Electromagnetic control |
Electromagnetic control |
|
Static linear control |
50N/cm |
56N/cm |
|
Nominal amplitude |
0.5mm |
0.5mm |
|
Vibration frequency |
70Hz |
70Hz |
|
Exciting force |
25KN |
28KN |
|
Water tank |
25L |
60L |
|
Hydraulic oil tank |
6.5L |
35L |
|
Engine model |
CF178F/CD180 |
Gasoline GX390/diesel engine |
|
Power |
6HP/7HP |
11HP/13HP |
|
Steel wheel size |
Before:φ580mm*700mm Rear:φ425mm*500mm |
φ540mm*800mm*2 |
|
Net weight |
780kg |
1000kg |
|
Starting mode |
Hand and electric |
Hand and electric |
|
|
||
|
Model |
AWR-1.2 |
AWR-2.0 |
|
Walk speed |
0-6km/h |
0-8km/h |
|
Gradeability |
30% |
30% |
|
Drive type |
Hydraulic double drive |
Hydraulic transmission |
|
Vibration control |
Electromagnetic control |
Hydraulic vibration |
|
Static linear control |
56N/cm |
55N/cm |
|
Nominal amplitude |
0.5mm |
0.6mm |
|
Vibration frequency |
70Hz |
65Hz |
|
Exciting force |
30KN |
30KN |
|
Water tank |
55L |
100L |
|
Hydraulic oil tank |
6.5L |
60L |
|
Engine model |
CF186F |
403D/GX630/CF13/diesel engine |
|
Power |
8.5hp |
25HP/20HP/13HP |
|
Steel wheel size |
Before:φ530mm*740mm Rear:φ530mm*800mm |
φ560mm*900mm*2 |
|
Net weight |
1200kg |
2000kg |
|
Starting mode |
Hand and electric |
Hand and electric |
Rubber Wheel Hydraulic Road Roller Technical Parameters:
|
Model |
AWR-6.0 |
AWR-7.0 |
AWR-8.0 |
|
Gradeability |
30% |
||
|
Walk speed |
0-12km/h |
0-14km/h |
|
|
Vibration frequency |
46hz |
||
|
Engine model |
CF490B |
YN4102Z |
|
|
Engine power |
40kw |
76kw |
|
|
Vibration wheel width |
1450mm |
1650mm |
1850mm |
|
Vibration wheel diameter |
1000mm |
1100mm |
1200mm |
|
Quality of work |
6000kg |
7000kg |
8000kg |
|
Size |
4450*1650*2650mm |
4550*1850*2650mm |
4850*2000*2750mm |
1.With international famous bearings.
2.High gradeability, more flexible.
3.Plastic treated, anti-rust, anti- corrosion and beautiful.
4.Adopts Import engine, excellent performance, easy to start-up.
5.Equipped with large capacity water tank, reduce the return water trouble.
6.Water cooled radiator.
7.The imported hydraulic system.
8.Infinitely variable speeds, hydraulic steering, walk forward and backward.
9.Electric startup, hydraulic vibration.
Road roller is mainly used for compaction of asphalt surface, compaction of gravel, sand and other projects. Due to the excellent welt, particularly suitable for foundation ditch, walkways and cycle paths, parking lots and all types of repair works.
