Quick Details
-
Resolution:
-
0.1dB
-
Accuracy:
-
± 1dB
-
Frequency Weighting:
-
"A" / "C" / "F" (Flat)
-
Time Weighting:
-
"Fast" ( 125ms ) / "Slow" ( 1 second )
-
Microphone:
-
1/2 inch electret condenser type
-
Memory:
-
Store 30 group measurement conditions and data
-
Built In Calibration Signal:
-
94dB at 1kHz (sinusoidal)
-
Alarm Value Set:
-
30~130 dB
-
Frequency Range:
-
20~12,500 Hz
-
Alarm Output:
-
LED and optional relay contact (NC)
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
VTSYIQI
-
Model Number:
-
AS-156B-Kelly
-
Resolution:
-
0.1dB
-
Accuracy:
-
± 1dB
-
Frequency Weighting:
-
"A" / "C" / "F" (Flat)
-
Time Weighting:
-
"Fast" ( 125ms ) / "Slow" ( 1 second )
-
Microphone:
-
1/2 inch electret condenser type
-
Memory:
-
Store 30 group measurement conditions and data
-
Built In Calibration Signal:
-
94dB at 1kHz (sinusoidal)
-
Alarm Value Set:
-
30~130 dB
-
Frequency Range:
-
20~12,500 Hz
-
Alarm Output:
-
LED and optional relay contact (NC)
Digital Sound Level Meter Gauge with Resolution 0.1 dB Accuracy Plus or Minus 1 dB Leq 35 to 130 dB
Product Description:
The Sound Level Meter is divided into two types: ( AS-156A Accuracy : ±2dB), (AS-156B Accuracy : ±1dB ). Can memorize 30 groups of measurement results and measuring conditions. Permits choice “A” / “C” / “F” weighting and “Fast” / “Slow” response times. Offers 4 measurement parameters: Lp ( soundlevel). Leq (Equivalent Continuous A Sound Level). Lmax (Maximum Sound Level) and LN (Percent of all readings over alarm value set).
Product Feature:
1.DC output :1 0 m V / d B.
2.Auto range selection and digital display with no guessing errors.
3.Can memorize 30 groups of measurement results and measuring conditions.
4. Permits choice “A”, “C” , “F” weighting and “Fast” / “Slow” response times.
5.Offers 4 measurement parameters: Lp (sound level); Leq (Equivalent Continuous A Sound Level ); Lmax ( Maximum Sound
Level) and LN (Percent of all readings over alarm value set ).
6.Use USB data output with connection PC.
7.Provide Bluetooth data outputchoice.
Specification:
| Resolution | 0.1dB |
| Accuracy | ± 1dB |
| Measurable Parameters |
Lp (sound level)
Leq (Equivalent Continuous A Sound Level) Lmax (Maximum Sound Level) LN (Percent of all readings over alarm value set) |
| Measuring Range |
Lp: 30~130dB
Leq: 35~130dB LN: 0~100% |
| Frequency Weighting | “A” / “C” / “F” (Flat) |
| Time Weighting | “Fast” ( 125ms ) / “Slow” ( 1 second ) |
| Microphone | 1/2 inch electret condenser type |
| Memory | Store 30 group measurement conditions and data |
| Built In Calibration Signal | 94dB at 1kHz (sinusoidal) |
| Alarm Value Set | 30~130 dB |
The battery is not included in the package! ! !
