- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Kyocera
-
Size:
-
4.1 inch
-
Backlight:
-
None
-
Resolution:
-
1280(W) * 3[R.G.B] * 640(H)
-
LCD Type:
-
TFT / Normally black-mode / Transmissive
-
Front polarization axis angle:
-
0° (Horizontal direction)
-
Data transfer:
-
LVDS(JEIDA or VESA Format) data transfer 8bit or 6bit + GPU + SPI
-
Active Area:
-
92.54(W) x 46.27(H)
-
Outline Dimension:
-
106.9(W) *61.9(H) *2.9(D)
-
Weight:
-
32.3g
-
Warranty:
-
12 Months
Quick Details
-
Type:
-
TFT
-
Display Size:
-
4.1 inch
-
Supplier Type:
-
TFT / Normally black-mode / Transmissive
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Kyocera
-
Size:
-
4.1 inch
-
Backlight:
-
None
-
Resolution:
-
1280(W) * 3[R.G.B] * 640(H)
-
LCD Type:
-
TFT / Normally black-mode / Transmissive
-
Front polarization axis angle:
-
0° (Horizontal direction)
-
Data transfer:
-
LVDS(JEIDA or VESA Format) data transfer 8bit or 6bit + GPU + SPI
-
Active Area:
-
92.54(W) x 46.27(H)
-
Outline Dimension:
-
106.9(W) *61.9(H) *2.9(D)
-
Weight:
-
32.3g
-
Warranty:
-
12 Months
|
Tems
|
|
Unit
|
Specifications
|
|
||
|
LCD Type
|
|
|
without touch,TFT / Normally black-mode / Transmissive
|
|
||
|
Size
|
|
inch
|
4.1
|
|
||
|
Model
|
|
|
A0410AA65306-NN-AB
|
|
||
|
Resolution
|
|
|
1280(W) × 3[R.G.B] × 640(H)
|
|
||
|
Pixel pitch
|
|
mm
|
0.0241(W) ×3[R.G.B] × 0.0723 (H)
|
|
||
|
Pixel arrangement
|
|
|
RGB stripe
|
|
||
|
Surface treatment
|
|
|
Glare / Surface hardness : Min.3H (JIS K 5600)
|
|
||
|
Data transfer
|
|
|
LVDS(JEIDA or VESA Format) data transfer 8bit or 6bit + GPU + SPI
|
|
||
|
Driver IC
|
|
|
PTC (Princeton Technology Corporation) PT16205F
|
|
||
|
Backlight
|
|
|
None
|
|
||
|
Active Area
|
|
mm
|
92.54(W) x 46.27(H)
|
|
||
|
Outline Dimension
|
|
mm
|
106.9(W) ×61.9(H) × 2.9(D) Without FPC
|
|
||
|
Front polarization axis angle
|
|
|
0° （Horizontal direction）
|
|
||
|
Color depth
|
|
|
16.7M colors
|
|
||
|
Operating Temperature
|
|
℃
|
-40~105
|
|
||
|
Storage Temperature
|
|
℃
|
-40~105
|
|
||
|
RoHS regulation
|
|
|
This product satisfies material Europe ELV requirement of Europe ELV instructions and RoHS regulation.
|
|
||
Q1. What are the advantages of Yuewei display？
A1.
The original brand agent, the products are in stock,
Fast delivery time
, can be supplied at any time, 24 hours online service, the products have passed strict testing and certification, and the seller is guaranteed.
Q2:
Can we get some screen drivers and wires?
A2:
Sure.
It can also be customized according to your needs
Q3.how can we guarantee quality?
Q3.
All of our screens are all new with original packaging, passed the international inspection standards, well guaranteed.If there is any quality issue, we will surely solve it within 1-2 working days.
Warranty 12 months.
Q4. How long will it be delivered?
A4.
We will ship the goods within 1-2 days after your payment. And we will send you the tracking number the next day after the goods are shipped.
Q5. what can you buy from Yuewei?
A5.
TFT L
CD module, LCD panel, LCD screen, capacitive touch, resistive touch, display, all-in-one, driver board, wire.
