Quick Details
-
Drilling Speed:
-
120-560rpm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Raintech
-
Model Number:
-
PLD3030
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
5990*6050*3200
-
Power (kW):
-
23
-
Weight (KG):
-
24000 KG
-
Marketing Type:
-
New Product 2024
-
Name:
-
Multi-spindle CNC Drilling Machine For Large Plates
-
Model:
-
PLD3030
-
Stack thickness(mm):
-
200
-
Processing range (mm):
-
3000*3000
-
Drilling diameter(mm):
-
50
-
Function:
-
drilling steel plates/sheets
-
Processing:
-
iron tube /flanges/plate/sheet
-
Controlling mode:
-
cnc ,automatic
-
Precision:
-
High Precision
-
Usage:
-
Metal Drilling Milling
Quick Details
-
type:
-
planar Drilling Machine
-
Max. Drilling Dia. (mm):
-
50
-
Range of Spindle Speed(r.p.m):
-
120 - 560 r.p.m
-
Drilling Speed:
-
120-560rpm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Raintech
-
Model Number:
-
PLD3030
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
5990*6050*3200
-
Power (kW):
-
23
-
Weight (KG):
-
24000 KG
-
Marketing Type:
-
New Product 2024
-
Name:
-
Multi-spindle CNC Drilling Machine For Large Plates
-
Model:
-
PLD3030
-
Stack thickness(mm):
-
200
-
Processing range (mm):
-
3000*3000
-
Drilling diameter(mm):
-
50
-
Function:
-
drilling steel plates/sheets
-
Processing:
-
iron tube /flanges/plate/sheet
-
Controlling mode:
-
cnc ,automatic
-
Precision:
-
High Precision
-
Usage:
-
Metal Drilling Milling
Product Description
1.The machine mainly consists of the bed and the longitudinal slide table ,gantry and the horizontal slide table , the vertical sliding pillow drilling power box , the work table ,the electric control system, the hydraulic system,the cooling system,the chip system ,the centralized lubrication system and so on.
2.The machine adopts movable gantry and fixed worktable ,save the floor area.
3.The spindle motor uses a special servo motor to drive the spindle through the synchronous belt, stepless speed regulation ,low speed torque , can withstand heavy cutting load ,and can be suitable for high-speed machining of hard alloy tools.
Product Parameters
|
Product name
|
CNC drilling machine
|
|
Bed Material
|
Gray Iron Casting
|
|
Feed Method
|
Servo Feed (ball screw)
|
|
Rotation Speed
|
0-10000 rpm/min
|
|
Control System
|
SIEMENS system
|
|
Stack Workpeice Thickness
|
300mm
|
|
Spindle Method
|
BT40/BT50 (Accept customization)
|
|
Clamping method
|
T slot
|
|
ATC
|
≥6
|
|
Max.Tapping Diameter
|
M32
|
Product Details
The bed&worktable is made of high-qualitygray iron (HT300), with good rigidity andstrong stability.A number of transverseT-slots are arranged on the top to clampthe workpiece, (when installing, fix anumber of ground anchors to better fix thebed and improve the stability of themachine tool.)
T-type ram structure power head, the mainshaft motor adopts a special servo motor forthe main shaft to drive the main shaftthrough a synchronous belt, low speed andlarge torque, which can not only bear heavycutting load, but also suitable for high-speedmachining of cemented carbide tools
Adopt Taiwan precision spinde (high-speedinternal cooling),spindle taper BT40/50, withbutterfly spring hydraulic broach mechanism,(hydraulic cylinder to loosen the tool, it is veryconvenient to change the tool. )The speed is3000 r/min, and the processing efficiency ishigh.
Equipped with a flat chain type automaticchip conveyor and collector for automaticcollection of iron chips.
Equipped with a centralized lubricationdevice, which can automatically lubricatevarious transmissions such as guide railslead screws and bearings
Adopts a full set of Siemens 808D busversion control system, and is equipped withRS232 interface and LCD liquid crystaldisplay. (The drilling coordinates can bedirectly converted from CAD/CAM, which isconvenient for programming, storage,display and communication.)
