100% genuine high quality A-grade solar inverter with factory QR code on it. Not fake or used or bad quality inverter!!!
Explore More Products
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Felicitysolar
-
Model Number:
-
IVPA7548
-
Input Voltage:
-
DC48V
-
Output Voltage:
-
AC 110V/220V
-
Output Current:
-
60A
-
Output Frequency:
-
50HZ/60HZ
-
Size:
-
607*540*290MM
-
Certificate:
-
CE, CE ROHS
-
Warranty:
-
2 years, 2 Years
-
Weight:
-
50 KG
-
Inverter type:
-
MPPT pure sine wave inverter
-
Output waveform:
-
Pure Sine Wave
-
Efficiency:
-
>95%
-
Load Power (W):
-
6000W
-
LCD display:
-
Charge mode & Utility Mode & Battery Mode & Fault Mode
-
OEM:
-
Accepted
-
Application:
-
Home Appliance
-
MPPT Solar Controller:
-
80A
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
95%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Felicitysolar
-
Model Number:
-
IVPA7548
-
Input Voltage:
-
DC48V
-
Output Voltage:
-
AC 110V/220V
-
Output Current:
-
60A
-
Output Frequency:
-
50HZ/60HZ
-
Size:
-
607*540*290MM
-
Certificate:
-
CE, CE ROHS
-
Warranty:
-
2 years, 2 Years
-
Weight:
-
50 KG
-
Inverter type:
-
MPPT pure sine wave inverter
-
Output waveform:
-
Pure Sine Wave
-
Efficiency:
-
>95%
-
Load Power (W):
-
6000W
-
LCD display:
-
Charge mode & Utility Mode & Battery Mode & Fault Mode
-
OEM:
-
Accepted
-
Application:
-
Home Appliance
-
MPPT Solar Controller:
-
80A
To become a distributor or agent of Felicitysolar, please contact us！！！
We can ship from 30+
Overseas branches
in the
United States, the European Union, Nigeria, South Africa, the Philippines,Myanmar, Dubai, Mali...
and provide fast transportation services. If you need it, please click here to contact us directly.
Features
·Bypass charging function,AC charge available When the unit off.
·Built-in MPPT Controller.
·80-140V/90-280VACWide input voltage.
·110V/220V Double line wire port.
·Grid electricity and battery power priority is optional.
·Higher charging current and adjustable.
·Communicate with felicity MPPT charge controller.
·Intelligent protection,higher class of security.
|
Model
|
IVPA3524
|
IVPA5048
|
IVPA7548
|
IVPA10048
|
||||
|
Rated Output Power(VA)
|
3500VA
|
5000VA
|
7500VA
|
10000VA
|
||||
|
Rated Output Power(W)
|
2800W
|
4000W
|
6000W
|
8000W
|
||||
|
Nominal DC Input Voltage
|
24V
|
48V
|
48V
|
48V
|
||||
|
Input Voltage Wavelom
|
Sinusoldal(Utility or generator)
|
|
|
|
||||
|
Teriminal connection
|
L-N
|
|
HOT1-HOT2
|
|
||||
|
Nominal Input Voltage
|
120Vac
|
|
220Vac
|
|
||||
|
Nominal Input Frequency
|
50Hz/60Hz
|
|
|
|
||||
|
Over-Load Protection(SMPS load)
|
Overcurrent protector
|
air switch protection
|
Overcurrent protector
|
air switch protection
|
||||
|
Output Short Circut Protection
|
Overcurrent protector
|
air switch protection
|
Overcurrent protector
|
air switch protection
|
||||
|
Effidency(Line mode)
|
≥95%
|
|
|
|
||||
|
Geral Specification
|
|
|
|
|
||||
|
Operating temperature
|
0℃~40℃
|
|
|
|
||||
|
Storage temperature
|
-15℃~60℃
|
|
|
|
||||
|
Net Weight(KG)
|
31.0KG
|
35.5KG
|
41.6KG
|
58.5KG
|
||||
|
Gross Weight(KG)
|
34.3KG
|
39.2KG
|
44.8KG
|
70.6KG
|
||||
|
Product Size(D*W*H)
|
472x391x195mm
|
525x420x195mm
|
|
615x420x195mm
|
||||
|
Package Dimension(D*W*H)
|
552x408x290mm
|
607x540x290mm
|
|
690x480x335mm
|
||||
