Quick Details
-
Production Capacity:
-
other
-
Weight (KG):
-
1
-
Voltage:
-
220V/50HZ
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FORLONG
-
Dimension(L*W*H):
-
800*1000*1800mm
-
After-sales Service Provided:
-
Field installation, commissioning and training
-
Certification:
-
CE/ISO9001
Quick Details
-
Function:
-
FILLING, Sealing
-
Packaging Type:
-
Bags, Film, Pouch
-
Packaging Material:
-
Plastic
-
Production Capacity:
-
other
-
Weight (KG):
-
1
-
Voltage:
-
220V/50HZ
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FORLONG
-
Dimension(L*W*H):
-
800*1000*1800mm
-
After-sales Service Provided:
-
Field installation, commissioning and training
-
Certification:
-
CE/ISO9001
SJIII-S100 AUTOMATIC LIQUID (PASTE STATE) PACKING MACHINE
Characteristic:
1.Back sealing, three-side sealing, four-side sealing packing method
2..The packing data and adjustment can be displayed on the screen. The user can directly operate it on it.
3.Assembled with a photoelectric controller to ensure that its packing bag figure are perfect.
4.It can automatically finish making-bag, metering, filling, sealing, cutting, counting and printing batch number.
5.The body and the parts touching the material are made of stainless steel.
Suitable material:
It is applicable for packing the liquid like hairdressing water, hair conditioner , lotion, soy sauce, cough syrup, agricultural
chemicals, wine and sauce.
Characteristic:
1.Back sealing, three-side sealing, four-side sealing packing method
2..The packing data and adjustment can be displayed on the screen. The user can directly operate it on it.
3.Assembled with a photoelectric controller to ensure that its packing bag figure are perfect.
4.It can automatically finish making-bag, metering, filling, sealing, cutting, counting and printing batch number.
5.The body and the parts touching the material are made of stainless steel.
Suitable material:
It is applicable for packing the liquid like hairdressing water, hair conditioner , lotion, soy sauce, cough syrup, agricultural
chemicals, wine and sauce.
|
Type
|
SJIII-S100
|
SJIII-S300
|
SJIII-S500
|
|
Bag-making length(mm)
|
50-150
|
50-300
|
80-300
|
|
Bag-making width(mm)
|
25-120
|
70-190
|
90-190
|
|
Packing film width(mm)
|
60-240
|
160-380
|
200-380
|
|
Packing capacity(ml)
|
5-100
|
50-1000
|
200-2000
|
|
Packing speed(bags/min)
|
30-60
|
20-40
|
15-30
|
|
Power (kw)
|
1.6
|
1.6
|
1.6
|
|
Air power (M pa)
|
0.65
|
0.65
|
0.65
|
|
Air consumption (L/min)
|
150
|
180
|
200
|
|
Overall dimension (mm)
|
760*1380*1700
|
900*1800*2040
|
900*2000*2040
|
|
Weight (kg)
|
300
|
480
|
650
|
