Compact in design, 49m pump mounted on a 4-axle truck.
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 6 arms with unfolding height 9.5m only,which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, itmonitors the pump intelligently on working data agement,real-time
diagnostics, alarm logging, and service interval notice.
- Product Details
- {{item.text}}
Quick Details
-
Productivity:
-
170cbm/h, 170M³/H
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Top Brand
-
Weight:
-
34000 kg
-
Dimension(L*W*H):
-
12380*2550*4000mm
-
Dimensions:
-
12380*2550*4000mm
-
Max.Engine power:
-
287kw
-
Max.grade-ability:
-
38%
-
Max.speed:
-
90Km
-
Approachh angle:
-
31°
Quick Details
-
Power Type:
-
Diesel
-
Max. vertical conveying distance:
-
48.6m, 48.6m
-
Max. horizontal conveying distance:
-
43.6m, 43.6m
-
Productivity:
-
170cbm/h, 170M³/H
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Top Brand
-
Weight:
-
34000 kg
-
Dimension(L*W*H):
-
12380*2550*4000mm
-
Dimensions:
-
12380*2550*4000mm
-
Max.Engine power:
-
287kw
-
Max.grade-ability:
-
38%
-
Max.speed:
-
90Km
-
Approachh angle:
-
31°
Contact Way
Email:april@tewrex.com
Wechat/Mobile/Whatsapp:+86 13041422703
Web:www.tewrex.com
Company name:Tewrex Suzhou subsidiary
Web:www.tewrex.com
Company name:Tewrex Suzhou subsidiary
Address: Room 602, Building 2,Tiandu Building,No.211Changjiang Road,High-tech Zone, Suzhou
City
Product Description
Product descriptions from the supplier
Product descriptions from the supplier
• Rich in configurations and high quality components.
• Boom with damping technology.
• Stabilization control on boom.
• Multilingual -machine interface system.
• PWM+CAN dual communication mode remote control
• Boom with damping technology.
• Stabilization control on boom.
• Multilingual -machine interface system.
• PWM+CAN dual communication mode remote control
|
Model
|
|
Unit
|
49X-6RZ-4
|
|
|
Pump Unit
|
Maximum pressure on concrete
|
m3/h
|
180
|
|
|
|
Maximum pressure on concrete
|
bar
|
113
|
|
|
|
Conc. cylinders (diam. x stroke)
|
mm
|
260×2100
|
|
|
|
Hydraulic circuit
|
|
Closed
|
|
|
Boom Section
|
Maximum vertical reach
|
m
|
48.6
|
|
|
|
Maximum horizontal distance
|
m
|
43.6
|
|
|
|
Minimum unfolding height
|
m
|
12.9
|
|
|
|
Section numbers
|
|
6
|
|
|
|
Boom type
|
|
RZ
|
|
|
|
Pipeline diameter
|
mm
|
125
|
|
