Quick Details
-
Brand Name:
-
RIDCN
-
Usage:
-
Pipe Clamp
-
Size:
-
Customized Sizes Acceptable
-
Material Choice:
-
SS316/SS304/SS201
-
OEM:
-
Warmly Welcomed
-
Sample:
-
Availble
-
Application:
-
Connection
-
Function:
-
Fixed Tube
Quick Details
-
Measurement system:
-
INCH, Metric
-
Material:
-
Stainless steel
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
RIDCN
-
Usage:
-
Pipe Clamp
-
Size:
-
Customized Sizes Acceptable
-
Material Choice:
-
SS316/SS304/SS201
-
OEM:
-
Warmly Welcomed
-
Sample:
-
Availble
-
Application:
-
Connection
-
Function:
-
Fixed Tube
- Material: band and housing are 304 stainless steel
- Band Width:12.7mm(1/2 inch)
- Band Thickness: 0.5mm/0.6mm/0.7mm
- Screw: 8mm(5/16 inch) slotted hex head screw (zinc-plated steel, 304 stainless steel and 410stainless steel are optional)
- Based on the general purpose worm drive hose clamp, the inner shield can provide superb sealing characteristics and is safe for all soft hoses. The electrophoretic paint make the clamps better corrosion-resistant. It can be used in various fields, like automobile,industrial machine,marine, agriculture, construction,etc.
| Part NO. | Clamping Range | Bandwidth | Torque |
| (mm) | (mm) | (N.m) | |
| 39W | 26-39 | 12.7 | 9 |
| 56W | 39-56 | 12.7 | 9 |
| 59W | 42-59 | 12.7 | 9 |
| 65W | 48-65 | 12.7 | 9 |
| 75W | 58-75 | 12.7 | 9 |
| 85W | 68-85 | 12.7 | 9 |
| 95W | 78-95 | 12.7 | 9 |
| 105W | 85-105 | 12.7 | 9 |
| 120W | 100-120 | 12.7 | 9 |
| 140W | 120-140 | 12.7 | 9 |
| 170W | 150-170 | 12.7 | 9 |
|
Note:We customize clamps according to your special requirements.
Other sizes and alternate materials are also available. |
|||
