Quick Details
-
Size:
-
20 40 45 53 Feet
-
Place of Origin:
-
Shandong, China
-
Product name:
-
utility dump semi box trailer
-
USAGE:
-
utility cargo transport
-
Logo:
-
By customer Needs
-
Condition:
-
New Made / Customize by needs
-
Axle Style:
-
American /Germany 13-20Tons
-
Suspension:
-
Bogie/Air/Mechanic/Rigid Optional
-
Aftersale:
-
1 year
-
Color:
-
Customers Optional
-
Certification:
-
BV ISO CCC ASME
Quick Details
-
Type:
-
Semi-Trailer
-
Max Payload:
-
45 - 100 Tons
-
Brand Name:
-
ELEPH
-
Size:
-
20 40 45 53 Feet
-
Place of Origin:
-
Shandong, China
-
Product name:
-
utility dump semi box trailer
-
USAGE:
-
utility cargo transport
-
Logo:
-
By customer Needs
-
Condition:
-
New Made / Customize by needs
-
Axle Style:
-
American /Germany 13-20Tons
-
Suspension:
-
Bogie/Air/Mechanic/Rigid Optional
-
Aftersale:
-
1 year
-
Color:
-
Customers Optional
-
Certification:
-
BV ISO CCC ASME
Cargo Transport Box Body Truck Semi Trailer
|
Cargo Transport Box Body Truck Semi Trailer |
|||||
|
Dimension(Optional) |
Axle N o. |
Rated Load (kg) |
Tire No. |
Tire Size |
|
|
20ft |
2 |
40000 |
8 |
825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier) |
|
|
40ft 45ft 48ft 53ft |
3 |
60000 |
12 |
||
|
40ft 45ft 48ft 53ft |
4 |
75000 |
16 |
||
|
Manufacture |
Qingdao Eleph Industry & Trade Co., Ltd |
||||
|
Wheel Base (mm) |
1310 |
||||
|
leaf-spring Pcs |
10 |
||||
|
Axle |
13/16/18 T |
||||
|
Suspension |
Heavy Duty Mechanic Suspension with Leaf Springs |
||||
|
Main Beam Material |
Q 345 B manganese plates, automatic submerged arc welded |
||||
|
Brake System |
Dual line braking system with automatic braking system/chambers |
||||
|
Brake Air Chamber |
Double Model |
||||
|
Kingpin |
2' or 3.5' Interchangeable |
||||
|
Landing gear |
28T loading capacity with 80T static lifting capacity. |
||||
|
Platform |
4-6 mm diamond steel plate |
||||
|
Brake System |
Dual Lines Braking System With Automatic Air Chambers |
||||
|
Brake Air Chamber |
Four double and two single chamber |
||||
|
Electrical System |
24V, 7 core socket, lights according to European standards. |
||||
|
Mainbeam Size |
Upper plate |
14mm |
|||
|
Lower plate |
16mm |
||||
|
Mid Web |
8 mm |
||||
|
Height |
500-520mm |
||||
|
Tool Box |
1 box of standard tools |
||||
|
Application |
For animal/livestock/coal/grain bulk cargo transport |
||||
|
Box Height |
2M |
||||
