Cutter 16mn 1000mm Hard Rock Cfa Borehole Drilling Machine Rig Used Pile Driver Soil Tractor Hydraulic Auger Drill For Sale

Unicorn Drill Drilling Auger & Continuous Flight Auger (CFA) adopt the high-carbon steel (Q345B, 16Mn, Q195-Q345, etc.) and special drilling bits (B47K20H, B47K19H, B47K17H, 3050, 3060, 3065,C30, C31HD, B85, B43H,18TL, 18HD, 25VIP, 18VIP,  25T, 25HD, 22T,833-18,855 25,18PN/LK,25PN/LK ) angle to keep the drilling strength and efficiency.

Purchase the standard drilling Augers.

1)Single Cut Conical Rock Auger & Double Cut Conical Rock Auger

Main Applications: Single Cut Auger are suitable for drilling in medium to strong rock (15-60 Mpa). double cut auger is recommended in uncased bores or for bigger diameters.

Features: Sturdy and wearable rock pilot for accurate positioning.

Hard facing strips on flights for wear protection.

Kelly box: 130*130, 150*150, 200*200 or as required (optionl).

CONICAL AUGER TECHNICAL DATA

2)Single Cut Flat or Butterfly Auger & Double Cut Flat or Butterfly Auger

*Flat or butterfly rock auger

Mian Applications: Single cut flat or butterfly rock auger are suitable for drilling in very dense sand and gravel, weak rock (<5 Mpa). Double cut auger is recommended in uncased bores or for bigger diameters and secant pile walls.

Features: Sturdy and wearale rock pilots for accurate poitioning.

Hard facing strips on flights for wear protection.

Kelly box: 130*130, 150*150, 200*200 or as required (optional).

FLAT OR BUTTERFLY ROCK AUGER TECHNICAL DATA

*Flat or butterfly soil auger

Main Applications: Single cut flat soil auger are suitable for drilling in soft to stiff silt and clay, loose to medium dense  sand and gravel. Double cut flat soil auger is recommended for uncased bores or for bigger dimeters.

Features: Fish-tial pilots for accurate positioning.

Hard-facing strips on flights for wear protection.
Kelly box: 130*130, 150*150, 200*200 or as required (optional).

FLAT OR BUTTERFLY SOIL AUGER TECHNICAL DATA

Customized your own drilling Augers

(1). Kelly Box : design various type and size 130*130, 150*150,200*200 or as required .

(2) .Spiral Height: design as demand, according to the piling diameter and soil condition prolong or shorten, increase of efficiency by drilling more.

(3).Spiral Pitch:adjust the spiral pitch according to different working condition.

(4) .Cutter: single cutter or double cutter and with pilots or without pilots design as demand;

(5).Key Component Reinforce : strengthen the key component to extend life cycle.

(6).Model of Teeth:

Rock Bits : B47K20H, B47K19H, B47K17H, 3050, 3060, 3065,C30, C31HD, B85, B43H, etc.

Clay Teeth: 18TL, 18HD, 25VIP, 18VIP,  25T, 25HD, 22T,833-18,855, etc.
